DeskewCheckCommand Class
See Also  Members   Example
Leadtools.ImageProcessing.Core Namespace : DeskewCheckCommand Class



Support for this function will be discontinued in the next major release of LEADTOOLS. Use DeskewCommand instead. Rotates the specified image to straighten it.

Syntax

Visual Basic (Declaration)
Public Class DeskewCheckCommand
   Inherits RasterCommand
   Implements IRasterCommand
Visual Basic (Usage)Copy Code
Dim instance As DeskewCheckCommand
C#
public class DeskewCheckCommand : RasterCommand, IRasterCommand
C++/CLI
public ref class DeskewCheckCommand : public RasterCommand, IRasterCommand

Example

Run the DeskewCheckCommand on an image and straightens it.

Visual BasicCopy Code
Public Sub DeskewCheckCommandExample()
   RasterCodecs.Startup()
   Dim codecs As New RasterCodecs()
   codecs.ThrowExceptionsOnInvalidImages = True

   Dim leadImage As RasterImage = codecs.Load(LeadtoolsExamples.Common.ImagesPath.Path + "Clean.tif")

   ' Prepare the command
   Dim command As DeskewCheckCommand = New DeskewCheckCommand
   'Deskew the image.
   command.Flags = DeskewCheckCommandFlags.DeskewImage Or DeskewCheckCommandFlags.DoNotFillExposedArea Or DeskewCheckCommandFlags.UseLineDetectionToDeskewCheck

   command.Run(leadImage)

   RasterCodecs.Shutdown()
End Sub
C#Copy Code
public void DeskewCheckCommandExample()
{
   // Load an image
   RasterCodecs.Startup();
   RasterCodecs codecs = new RasterCodecs();
   codecs.ThrowExceptionsOnInvalidImages = true;

   RasterImage image = codecs.Load(LeadtoolsExamples.Common.ImagesPath.Path + "Clean.tif");

   // Prepare the command
   DeskewCheckCommand command = new DeskewCheckCommand();
   //Deskew the image.
   command.Flags = DeskewCheckCommandFlags.DeskewImage | DeskewCheckCommandFlags.DoNotFillExposedArea;
   command.Run(image);

   RasterCodecs.Shutdown();
}

Remarks

This command is typically used to automatically straighten scanned images. This command is available in the Document\Medical Toolkits.

  • Like the DeskewCommand, you can use this method to automatically straighten scanned documents. With this command, the DeskewCommand class has been extended to work especially on bank check images. Different algorithms can be used (the normal deskew algorithm, a special bank check algorithm and a special line detection algorithm).
  • If the Flags property or the flags parameter of the Constructor contains DeskewCheckCommandFlags.ReturnAngleOnly, the command will update the Angle property without rotating the image.
  • This command includes an option to skip deskewing if the angle is very small.
  • The amount of rotation is limited to a maximum of 20 degrees in either direction. This command is intended for images, like scanned bank checks, that are mainly horizontal lines of text. The results are less predictable with other types of images.
  • This command does not support 12- or 16-bit grayscale or 48- or 64-bit color images, but will not throw an exception.
  • This command does not support signed data images.
  • This command does not support 32-bit grayscale images.
The following images demonstrate the use of the DeskewCheckCommand command on color, grayscale, and 1-bit images.

The original color image is shown in the following figure:

The deskewed color image is shown in the following figure:

The original grayscale image is shown in the following figure:

The deskewed grayscale image is shown in the following figure:

The original 1-bit image is shown in the following figure:

The deskewed 1-bit image is shown in the following figure:

For more information, refer to Introduction to Image Processing With LEADTOOLS and Deskewing.

Inheritance Hierarchy

System.Object
   Leadtools.ImageProcessing.RasterCommand
      Leadtools.ImageProcessing.Core.DeskewCheckCommand

Requirements

Target Platforms: Microsoft .NET Framework 2.0, Windows 98, Windows NT 4.0, Windows Millennium Edition, Windows 2000, Windows XP Home Edition, Windows XP Professional, Windows Server 2003 family
