FreeRadialBendCommand Class
See Also  Members   Example
Leadtools.ImageProcessing.SpecialEffects Namespace : FreeRadialBendCommand Class




Wraps the image along its radius on a 3D surface shaped by Curve. This command is available in the Raster Pro and above toolkits.

Syntax

Visual Basic (Declaration)
Public Class FreeRadialBendCommand
   Inherits RasterCommand
   Implements IRasterCommand
Visual Basic (Usage)Copy Code
Dim instance As FreeRadialBendCommand
C#
public class FreeRadialBendCommand : RasterCommand, IRasterCommand
Managed Extensions for C++
public __gc class FreeRadialBendCommand : public RasterCommand, IRasterCommand
C++/CLI
public ref class FreeRadialBendCommand : public RasterCommand, IRasterCommand

Example

Visual BasicCopy Code
ImageProcessing.SpecialEffects.FreeRadialBendCommand
   Public Sub FreeRadialBendCommandExample()
      RasterCodecs.Startup()
      Dim codecs As New RasterCodecs()
      codecs.ThrowExceptionsOnInvalidImages = True

      Dim leadImage As RasterImage = codecs.Load("C:\Program Files\LEAD Technologies\LEADTOOLS 15\Images\Master.jpg")

      ' Prepare the command
      Dim command As FreeRadialBendCommand = New FreeRadialBendCommand
      Dim UserPoint() As Point
      ReDim UserPoint(3)
      Dim CenterPoint As Point = New Point(leadImage.Width \ 2, leadImage.Height \ 2)
      Dim Curve() As Integer
      ReDim Curve(12)

      'Apply the filter
      UserPoint(0).X = 0
      UserPoint(0).Y = 0
      UserPoint(1).X = 3
      UserPoint(1).Y = 10
      UserPoint(2).X = 9
      UserPoint(2).Y = -10
      UserPoint(3).X = 12
      UserPoint(3).Y = 0

      EffectsUtilities.GetCurvePoints(Curve, UserPoint, CurvePointsType.Linear)
      command.Flags = FreeRadialBendCommandFlags.Color Or FreeRadialBendCommandFlags.Rotate
      command.CenterPoint = CenterPoint
      command.Scale = 200
      command.FillColor = New RasterColor(255, 0, 0)
      command.Curve = Curve
      command.Run(leadImage)
      codecs.Save(leadImage, "C:\Program Files\LEAD Technologies\LEADTOOLS 15\Images\Result.jpg", RasterImageFormat.Jpeg, 24)

      RasterCodecs.Shutdown()
   End Sub
C#Copy Code
ImageProcessing.SpecialEffects.FreeRadialBendCommand
      public void FreeRadialBendCommandExample()
      {
         // Load an image
         RasterCodecs.Startup();
         RasterCodecs codecs = new RasterCodecs();
         codecs.ThrowExceptionsOnInvalidImages = true;

         RasterImage image = codecs.Load(@"C:\Program Files\LEAD Technologies\LEADTOOLS 15\Images\Master.jpg");

         // Prepare the command
         FreeRadialBendCommand command = new FreeRadialBendCommand();
         System.Drawing.Point[] UserPoint = new System.Drawing.Point[4];
         System.Drawing.Point CenterPoint = new System.Drawing.Point(image.Width / 2, image.Height / 2);
         int[] Curve = new int[13];

         //Apply the filter
         UserPoint[0].X = 0;
         UserPoint[0].Y = 0;
         UserPoint[1].X = 3;
         UserPoint[1].Y = 10;
         UserPoint[2].X = 9;
         UserPoint[2].Y = -10;
         UserPoint[3].X = 12;
         UserPoint[3].Y = 0;

         EffectsUtilities.GetCurvePoints(Curve, UserPoint, CurvePointsType.Linear);
         for(int i = 0; i < Curve.Length; i++)
            Curve[i] /= 50;
         command.Flags = FreeRadialBendCommandFlags.Color | FreeRadialBendCommandFlags.Rotate;
         command.CenterPoint = CenterPoint;
         command.Scale = 200;
         command.FillColor = new RasterColor(255, 0, 0);
         command.Curve = Curve;
         command.Run(image);
         codecs.Save(image, @"C:\Program Files\LEAD Technologies\LEADTOOLS 15\Images\Result.jpg", RasterImageFormat.Jpeg, 24);

         RasterCodecs.Shutdown();
      }

Remarks

  • If the image has a region, the effect will be applied on the region only.
  • For an example, the following figure shows a image before the effect is applied.

    The following figure shows the same image after the effect has been applied.

  • This command supports 12 and 16-bit grayscale and 48 and 64-bit color images. Support for 12 and 16-bit grayscale and 48 and 64-bit color images is available only in the Document/Medical toolkits.
  • This command does not support signed data images.
  • This command does not support 32-bit grayscale images.
For more information, refer to Correcting Colors.

Inheritance Hierarchy

System.Object
   Leadtools.ImageProcessing.RasterCommand
      Leadtools.ImageProcessing.SpecialEffects.FreeRadialBendCommand

Requirements

Target Platforms: Microsoft .NET Framework 2.0, Windows 98, Windows NT 4.0, Windows Millennium Edition, Windows 2000, Windows XP Home Edition, Windows XP Professional, Windows Server 2003 family
