Miscellaneous Barcodes in LEADTOOLS
Show in webframe
LEADTOOLS prides itself on having the most comprehensive and robust toolkits on the market. Its extensive barcode libraries support a broad range of barcode symbols, including those used in smaller, specialized markets and industries.
Sample Barcode:
The Code 39 symbol, also known as USD-3 and Code 3 of 9, supports alphanumeric data and is widely used . It is the standard barcode used by the US Department of Defense and the Health Industry Bar Code Council (HIBCC). Code 39 supports the encoding of 43 different alphanumeric characters. Additionally, LEADTOOLS supports Code 39 "Full ASCII Mode" to support data using all 128 ASCII characters. In LEADTOOLS documentation this is referred to as "Code 39 Extended".
Leadtools.Barcode support:
|
LEADTOOLS symbology identifier |
BarcodeSymbology.Code3Of9 |
|
Data class |
Leadtools.Barcode.BarcodeData |
|
Read options |
Leadtools.Barcode.OneDBarcodeReadOptions |
|
Write options |
Leadtools.Barcode.OneDBarcodeWriteOptions |
Sample Barcode:
The Code 93 symbol, also known as USS-93, is similar to the Code 39 symbol, but offers the advantage of supporting the encoding of 47 (versus 43) different alphanumeric characters. Additionally, LEADTOOLS supports Code 93 "Full ASCII mode" symbols that encode data structures consisting of all 128 ASCII characters. In LEADTOOLS documentation this is referred to as "Code 93 Extended".
Leadtools.Barcode support:
|
LEADTOOLS symbology identifier |
BarcodeSymbology.Code93 |
|
Data class |
Leadtools.Barcode.BarcodeData |
|
Read options |
Leadtools.Barcode.OneDBarcodeReadOptions |
|
Write options |
Leadtools.Barcode.OneDBarcodeWriteOptions |
Sample Barcode:
The Code 32 symbol, also known as Italian Pharmacode, IMH, Codice 32 Pharmacode, Codice Farmaceutico Italiano and Radix 32 Barcode, is a superset of Code 39 and is used in Italy to identify pharmaceutical products.
Leadtools.Barcode support:
|
LEADTOOLS symbology identifier |
BarcodeSymbology.Code3Of9 |
|
Data class |
Leadtools.Barcode.BarcodeData |
|
Read options |
Leadtools.Barcode.OneDBarcodeReadOptions |
|
Write options |
Leadtools.Barcode.OneDBarcodeWriteOptions |
Sample Barcode:
The Code 11 symbol, also known as USD-8, supports the encoding of 0-9 and the dash (-) character and is used to identify telecommunications hardware.
Leadtools.Barcode support:
|
LEADTOOLS symbology identifier |
BarcodeSymbology.Code11 |
|
Data class |
Leadtools.Barcode.BarcodeData |
|
Read options |
Leadtools.Barcode.OneDBarcodeReadOptions |
|
Write options |
Leadtools.Barcode.OneDBarcodeWriteOptions |
Sample Barcode:
Patch code symbols are not true barcodes in the sense that patch codes do not encode data. They are used with scanners to separate batch scanning jobs and to control the scanner.
Leadtools.Barcode support:
|
LEADTOOLS symbology identifier |
BarcodeSymbology.PatchCode |
|
Data class |
Leadtools.Barcode.BarcodeData |
|
Read options |
Leadtools.Barcode.PatchCodeBarcodeReadOptions |
|
Write options |
Leadtools.Barcode.PatchCodeBarcodeWriteOptions |
