The Broker Host AddIn hosts the LEADTOOLS Modality Worklist WCF service.

Note: The PACS Framework server (Leadtools.Dicom.Service.exe) needs to be running in order to start, stop, or restart the Broker Host.

Access Broker Host configuration settings by clicking the Broker host icon ( ) from the Server Manager application with L19_SERVER32 selected. Doing so opens the following dialog:

The Broker Configuration dialog has the following fields:

• Broker Config File - Path to the WCF configuration file.
• Broker Status - Information about the availability of the Broker Host Service.
• Start - Starts the Broker Host Service
• Stop - Stops the Broker Host Service
• Restart - Restarts the Broker Host Service
