OceanCommandBitmapEffect Class
See Also  Members
Leadtools.Windows.Media.Effects.SpecialEffects Namespace : OceanCommandBitmapEffect Class




Reflects the image on an ocean surface. This command is available in the Raster Proo and above toolkits.

Syntax

Visual Basic (Declaration)
Public Class OceanCommandBitmapEffect
   Inherits RasterCommandBitmapEffect
Visual Basic (Usage)Copy Code
Dim instance As OceanCommandBitmapEffect
C#
public class OceanCommandBitmapEffect : RasterCommandBitmapEffect
Managed Extensions for C++
public __gc class OceanCommandBitmapEffect : public RasterCommandBitmapEffect
C++/CLI
public ref class OceanCommandBitmapEffect : public RasterCommandBitmapEffect

Example

Run the OceanCommandBitmapEffect on an image.

Remarks

  • For an example, see the following figure:

    The following figure shows the same image, after the effect has been applied:

    To obtain this effect, the following settings were used with the method:

    1. Amplitude = 15
    2. Frequency = 20
    3. LowerTransparency = true
    4. This command does not support 32-bit grayscale images.
  • This command supports 12 and 16-bit grayscale and 48 and 64-bit color images. Support for 12 and 16-bit grayscale and 48 and 64-bit color images is available only in the Document/Medical toolkits.
  • This command does not support signed data images.

Inheritance Hierarchy

System.Object
   System.Windows.Threading.DispatcherObject
      System.Windows.DependencyObject
         System.Windows.Freezable
            System.Windows.Media.Animation.Animatable
               System.Windows.Media.Effects.BitmapEffect
                  Leadtools.Windows.Media.Effects.RasterCommandBitmapEffect
                     Leadtools.Windows.Media.Effects.SpecialEffects.OceanCommandBitmapEffect

Requirements

Target Platforms: Microsoft .NET Framework 2.0, Windows 98, Windows NT 4.0, Windows Millennium Edition, Windows 2000, Windows XP Home Edition, Windows XP Professional, Windows Server 2003 family

See Also
