LensFlareCommand Class
See Also  Members
Leadtools.ImageProcessing.SpecialEffects Namespace : LensFlareCommand Class



Simulates the secondary reflections caused when bright lights are facing the camera lens. The lens flare is refracted into a series of lightened circles that surround the flare. This method is available in the Raster Pro and above toolkits.

Object Model

LensFlareCommand Class

Syntax

Visual Basic (Declaration)
Public Class LensFlareCommand
   Inherits Leadtools.ImageProcessing.RasterCommand
   Implements IRasterCommand
Visual Basic (Usage)Copy Code
Dim instance As LensFlareCommand
C#
public class LensFlareCommand : Leadtools.ImageProcessing.RasterCommand, IRasterCommand
C++/CLI
public ref class LensFlareCommand : public Leadtools.ImageProcessing.RasterCommand, IRasterCommand

Example

Run the Leadtools.ImageProcessing.SpecialEffects.LensFlareCommand on an image.

Visual BasicCopy Code
Public Sub LensFlareCommandExample()
   Dim codecs As New RasterCodecs()
   codecs.ThrowExceptionsOnInvalidImages = True

   Dim leadImage As RasterImage = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "Master.jpg"))

   ' Prepare the command
   Dim command As LensFlareCommand = New LensFlareCommand
   'Set the center point in the middle of the first square.
   command.CenterPoint = New LeadPoint(leadImage.Width \ 4, leadImage.Height \ 4)
   command.Brightness = 100
   command.Type = LensFlareCommandType.Type1
   command.Color = New RasterColor(100, 150, 10)
   ' Apply the lens flare effect to the image.
   command.Run(leadImage)
   codecs.Save(leadImage, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24)

End Sub

Public NotInheritable Class LEAD_VARS
   Public Const ImagesDir As String = "C:\Users\Public\Documents\LEADTOOLS Images"
End Class
C#Copy Code
public void LensFlareCommandExample()
   {
      // Load an image
      RasterCodecs codecs = new RasterCodecs();
      codecs.ThrowExceptionsOnInvalidImages = true;

      RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "Master.jpg"));

      // Prepare the command
      LensFlareCommand command = new LensFlareCommand();
      //Set the center point in the middle of the first square.
      command.CenterPoint = new LeadPoint(image.Width / 4, image.Height / 4);
      command.Brightness = 100;
      command.Type = LensFlareCommandType.Type1;
      command.Color = new RasterColor(100, 150, 10);
      // Apply the lens flare effect to the image.
      command.Run(image);
      codecs.Save(image, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24);

   }

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\Users\Public\Documents\LEADTOOLS Images";
}

Remarks

  • Secondary reflections are caused when bright lights are facing the camera lens. These reflections can show up as spots or banding. The command adds this effect to the image by controlling their number, position, brightness and size of the spots or banding. Each lens type has its own spot distribution and ray thickness.
  • This command supports 12- and 16-bit grayscale and 48- and 64-bit color images. Support for 12- and 16-bit grayscale and 48- and 64-bit color images is available only in the Document/Medical toolkits.
  • This command does not support signed data images.
  • For an example, see the following figure:

  • The following figure shows the same image, after the effect has been applied:

  • This command does not support 32-bit grayscale images.
For more information, refer to Correcting Colors.

Inheritance Hierarchy

System.Object
   Leadtools.ImageProcessing.RasterCommand
      Leadtools.ImageProcessing.SpecialEffects.LensFlareCommand

Requirements

Target Platforms: Microsoft .NET Framework 2.0, Windows 2000, Windows XP, Windows Server 2003 family, Windows Server 2008 family, Windows Vista, Windows 7
