DiffuseGlowCommand Class
See Also  Members
Leadtools.ImageProcessing.SpecialEffects Namespace : DiffuseGlowCommand Class



Adds a colored glow to an image's light or dark areas, making these areas shine with a neon glow. This method is available in the Raster Pro and above toolkits

Object Model

DiffuseGlowCommand Class

Syntax

Visual Basic (Declaration)
Public Class DiffuseGlowCommand
   Inherits Leadtools.ImageProcessing.RasterCommand
   Implements IRasterCommand
Visual Basic (Usage)Copy Code
Dim instance As DiffuseGlowCommand
C#
public class DiffuseGlowCommand : Leadtools.ImageProcessing.RasterCommand, IRasterCommand
C++/CLI
public ref class DiffuseGlowCommand : public Leadtools.ImageProcessing.RasterCommand, IRasterCommand

Example

Run the Leadtools.ImageProcessing.SpecialEffects.DiffuseGlowCommand on an image and applies the Diffuse Glow filter.

Visual BasicCopy Code
Public Sub DiffuseGlowCommandExample()
   Dim codecs As New RasterCodecs()
   codecs.ThrowExceptionsOnInvalidImages = True

   Dim leadImage As RasterImage = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "Master.jpg"))

   ' Prepare the command
   Dim fillColor As New RasterColor(255, 255, 255)
   Dim command As New DiffuseGlowCommand
   command.GlowAmount = 50
   command.ClearAmount = 50
   command.SpreadAmount = 10
   command.WhiteNoiseRange = 10
   command.GlowColor = fillColor
   command.Run(leadImage)
   codecs.Save(leadImage, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24)

End Sub

Public NotInheritable Class LEAD_VARS
   Public Const ImagesDir As String = "C:\Users\Public\Documents\LEADTOOLS Images"
End Class
C#Copy Code
public void DiffuseGlowCommandExample()
   {
      // Load an image
      RasterCodecs codecs = new RasterCodecs();
      codecs.ThrowExceptionsOnInvalidImages = true;

      RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "Master.jpg"));

      // Prepare the command
      RasterColor fillColor = new RasterColor(255, 255, 255);
      DiffuseGlowCommand command = new DiffuseGlowCommand () ;
      command.GlowAmount = 50;
      command.ClearAmount = 50;
      command.SpreadAmount = 10;
      command.WhiteNoiseRange = 10;
      command.GlowColor = fillColor;
      command.Run(image);
      codecs.Save(image, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24);

   }

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\Users\Public\Documents\LEADTOOLS Images";
}

Remarks

  • This command adds pixels randomly to the image. A glow is added based on a combination of the pixel colors and the glow color.
  • As an example, if you use the following image:

    And you were to call DiffuseGlowCommand using the following settings:
    Parameter Value
    GlowAmount 50
    ClearAmount 50
    SpreadAmount 10
    WhiteNoiseRange 10
    GlowColor white

    The following figure results:
  • If the image has a region, the effect will be applied on the region only.
  • This method supports 12- and 16-bit grayscale and 48- and 64-bit color images. Support for 12- and 16-bit grayscale and 48- and 64-bit color images is available only in the Document/Medical toolkits.
  • This method does not support signed data images.
  • This command does not support 32-bit grayscale images.
For more information, refer to Removing Noise.

Inheritance Hierarchy

System.Object
   Leadtools.ImageProcessing.RasterCommand
      Leadtools.ImageProcessing.SpecialEffects.DiffuseGlowCommand

Requirements

Target Platforms: Microsoft .NET Framework 2.0, Windows 2000, Windows XP, Windows Server 2003 family, Windows Server 2008 family, Windows Vista, Windows 7
