![](dotnetdiagramimages/Leadtools_ImageProcessing_SpecialEffects_Leadtools_ImageProcessing_SpecialEffects_FreePlaneBendCommand.png)
Visual Basic (Declaration) | |
---|---|
Public Class FreePlaneBendCommand Inherits Leadtools.ImageProcessing.RasterCommand Implements IRasterCommand |
Visual Basic (Usage) | ![]() |
---|---|
Dim instance As FreePlaneBendCommand |
C# | |
---|---|
public class FreePlaneBendCommand : Leadtools.ImageProcessing.RasterCommand, IRasterCommand |
C++/CLI | |
---|---|
public ref class FreePlaneBendCommand : public Leadtools.ImageProcessing.RasterCommand, IRasterCommand |
Run the Leadtools.ImageProcessing.SpecialEffects.FreePlaneBendCommand on an image.
Visual Basic | ![]() |
---|---|
Public Sub FreePlaneBendCommandExample() Dim codecs As New RasterCodecs() codecs.ThrowExceptionsOnInvalidImages = True Dim leadImage As RasterImage = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "Master.jpg")) ' Prepare the command Dim command As FreePlaneBendCommand = New FreePlaneBendCommand Dim UserPoint() As LeadPoint ReDim UserPoint(3) Dim Curve() As Integer ReDim Curve(12) 'Apply the filter UserPoint(0).X = 0 UserPoint(0).Y = 0 UserPoint(1).X = 3 UserPoint(1).Y = 10 UserPoint(2).X = 9 UserPoint(2).Y = -10 UserPoint(3).X = 12 UserPoint(3).Y = 0 EffectsUtilities.GetCurvePoints(Curve, UserPoint, CurvePointsType.Linear) command.Flags = FreePlaneBendCommandFlags.Color Or FreePlaneBendCommandFlags.Vertical command.Scale = 200 command.FillColor = New RasterColor(255, 0, 0) command.Curve = Curve command.Run(leadImage) codecs.Save(leadImage, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24) End Sub Public NotInheritable Class LEAD_VARS Public Const ImagesDir As String = "C:\Users\Public\Documents\LEADTOOLS Images" End Class |
C# | ![]() |
---|---|
public void FreePlaneBendCommandExample() { // Load an image RasterCodecs codecs = new RasterCodecs(); codecs.ThrowExceptionsOnInvalidImages = true; RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "Master.jpg")); // Prepare the command FreePlaneBendCommand command = new FreePlaneBendCommand(); LeadPoint[] UserPoint = new LeadPoint[4]; int[] Curve = new int[13]; //Apply the filter UserPoint[0].X = 0; UserPoint[0].Y = 0; UserPoint[1].X = 3; UserPoint[1].Y = 10; UserPoint[2].X = 9; UserPoint[2].Y = -10; UserPoint[3].X = 12; UserPoint[3].Y = 0; EffectsUtilities.GetCurvePoints(Curve, UserPoint, CurvePointsType.Linear); for(int i = 0; i < Curve.Length; i++) Curve[i] /= 50; command.Flags = FreePlaneBendCommandFlags.Color | FreePlaneBendCommandFlags.Vertical; command.Scale = 200; command.FillColor = new RasterColor(255, 0, 0); command.Curve = Curve; command.Run(image); codecs.Save(image, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24); } static class LEAD_VARS { public const string ImagesDir = @"C:\Users\Public\Documents\LEADTOOLS Images"; } |
- If the image has a region, the effect will be applied on the region only.
- For an example, the following figure shows an image before the effect is applied.
The following figure shows the same image after the effect has been applied.
- This command supports 12- and 16-bit grayscale and 48- and 64-bit color images. Support for 12- and 16-bit grayscale and 48- and 64-bit color images is available only in the Document/Medical toolkits.
- This command does not support signed data images.
- This command does not support 32-bit grayscale images.
System.Object
Leadtools.ImageProcessing.RasterCommand
Leadtools.ImageProcessing.SpecialEffects.FreePlaneBendCommand
Target Platforms: Microsoft .NET Framework 2.0, Windows 2000, Windows XP, Windows Server 2003 family, Windows Server 2008 family, Windows Vista, Windows 7
