AnnRedactionObject Class

Visual Basic
C#
WinRT C#
WinRT JavaScript
C++

[SerializableAttribute()]
public class AnnRedactionObject : AnnRectangleObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Declaration

<SerializableAttribute()>
Public Class AnnRedactionObject
   Inherits AnnRectangleObject
   Implements System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Usage

Dim instance As AnnRedactionObject

public sealed class AnnRedactionObject : System.ICloneable, IClosable //In WinRT the IDisposable interface is replaced by IClosable, ~Remove~

function Leadtools.Annotations.AnnRedactionObject()

[SerializableAttribute()]
public ref class AnnRedactionObject : public AnnRectangleObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

The redaction annotation object is a rectangle with default properties that are appropriate for blacking out an area. The Realize(RasterImageViewer) method lets you block the area on the image with the current object brush value. The Restore(RasterImageViewer) method lets you restore the area back. For more information about the redaction annotation object refer to AnnRedactionObject. For more information about the automated redaction annotation object, refer to Annotation Objects - Automated Features.

If you are interested in locking an object, refer to Implementing Annotation Security.

Visual Basic
C#
WinRT C#
WinRT JavaScript
Silverlight C#
Silverlight VB

Private Sub AnnRedactionObject_AnnRedactionObject(ByVal viewer As RasterImageViewer, ByVal container As AnnContainer)
   Dim redaction As AnnRedactionObject = New AnnRedactionObject()
   redaction.Bounds = New AnnRectangle(100, 100, 300, 300, AnnUnit.Pixel)
   container.Objects.Add(redaction)
   viewer.Invalidate(redaction.InvalidRectangle)
   MessageBox.Show(String.Format("Added. IsRealized: {0}, Objects in container: {1}", redaction.IsRealized, container.Objects.Count))

   ' realize the redaction object
   redaction.Realize(viewer)

   viewer.Invalidate(redaction.InvalidRectangle)
   MessageBox.Show(String.Format("Realized. IsRealized: {0}, Objects in container: {1}", redaction.IsRealized, container.Objects.Count))

   ' remove the redaction object from the container
   container.Objects.Remove(redaction)
   viewer.Invalidate()
   MessageBox.Show(String.Format("Removed. Objects in container: {0}", container.Objects.Count))

   ' add the redaction object back
   container.Objects.Add(redaction)
   viewer.Invalidate(redaction.InvalidRectangle)
   MessageBox.Show(String.Format("Added back. IsRealized: {0}, Objects in container: {1}", redaction.IsRealized, container.Objects.Count))

   ' restore the redaction object
   redaction.Restore(viewer)
   viewer.Invalidate(redaction.InvalidRectangle)
   MessageBox.Show(String.Format("Restored. IsRealized: {0}, Objects in container: {1}", redaction.IsRealized, container.Objects.Count))

   ' remove the redaction again from the container
   container.Objects.Remove(redaction)
   viewer.Invalidate()
   MessageBox.Show(String.Format("Removed. Objects in container: {0}", container.Objects.Count))
End Sub

private void AnnRedactionObject_AnnRedactionObject(RasterImageViewer viewer, AnnContainer container)
{
   AnnRedactionObject redaction = new AnnRedactionObject();
   redaction.Bounds = new AnnRectangle(100, 100, 300, 300, AnnUnit.Pixel);
   container.Objects.Add(redaction);
   viewer.Invalidate(redaction.InvalidRectangle);
   MessageBox.Show(String.Format("Added. IsRealized: {0}, Objects in container: {1}", redaction.IsRealized, container.Objects.Count));

   // realize the redaction object
   redaction.Realize(viewer);

   viewer.Invalidate(redaction.InvalidRectangle);
   MessageBox.Show(String.Format("Realized. IsRealized: {0}, Objects in container: {1}", redaction.IsRealized, container.Objects.Count));

   // remove the redaction object from the container
   container.Objects.Remove(redaction);
   viewer.Invalidate();
   MessageBox.Show(String.Format("Removed. Objects in container: {0}", container.Objects.Count));

   // add the redaction object back
   container.Objects.Add(redaction);
   viewer.Invalidate(redaction.InvalidRectangle);
   MessageBox.Show(String.Format("Added back. IsRealized: {0}, Objects in container: {1}", redaction.IsRealized, container.Objects.Count));

   // restore the redaction object
   redaction.Restore(viewer);
   viewer.Invalidate(redaction.InvalidRectangle);
   MessageBox.Show(String.Format("Restored. IsRealized: {0}, Objects in container: {1}", redaction.IsRealized, container.Objects.Count));

   // remove the redaction again from the container
   container.Objects.Remove(redaction);
   viewer.Invalidate();
   MessageBox.Show(String.Format("Removed. Objects in container: {0}", container.Objects.Count));
}

Target Platforms: Windows 7, Windows Vista SP1 or later, Windows XP SP3, Windows Server 2008 (Server Core not supported), Windows Server 2008 R2 (Server Core supported with SP1 or later), Windows Server 2003 SP2
