LensFlareCommand Class

Simulates the secondary reflections caused when bright lights are facing the camera lens. The lens flare is refracted into a series of lightened circles that surround the flare. This method is available in the Raster Pro and above toolkits.

Object Model

Syntax

Visual Basic
C#
WinRT C#
WinRT JavaScript
C++

public class LensFlareCommand : Leadtools.ImageProcessing.RasterCommand, Leadtools.ImageProcessing.IRasterCommand

'Declaration

Public Class LensFlareCommand
   Inherits Leadtools.ImageProcessing.RasterCommand
   Implements Leadtools.ImageProcessing.IRasterCommand

'Usage

Dim instance As LensFlareCommand

public sealed class LensFlareCommand : Leadtools.ImageProcessing.IRasterCommand

function Leadtools.ImageProcessing.SpecialEffects.LensFlareCommand()

public ref class LensFlareCommand : public Leadtools.ImageProcessing.RasterCommand, Leadtools.ImageProcessing.IRasterCommand

Remarks

Secondary reflections are caused when bright lights are facing the camera lens. These reflections can show up as spots or banding. The command adds this effect to the image by controlling their number, position, brightness and size of the spots or banding. Each lens type has its own spot distribution and ray thickness.
This command supports 12- and 16-bit grayscale and 48- and 64-bit color images. Support for 12- and 16-bit grayscale and 48- and 64-bit color images is available only in the Document/Medical toolkits.
This command does not support signed data images.
For an example, see the following figure:
The following figure shows the same image, after the effect has been applied:
This command does not support 32-bit grayscale images.

For more information, refer to Correcting Colors.

Example

Visual Basic
C#
WinRT C#
WinRT JavaScript
Silverlight C#
Silverlight VB

Public Sub LensFlareCommandExample()
   Dim codecs As New RasterCodecs()
   codecs.ThrowExceptionsOnInvalidImages = True

   Dim leadImage As RasterImage = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "Master.jpg"))

   ' Prepare the command
   Dim command As LensFlareCommand = New LensFlareCommand
   'Set the center point in the middle of the first square.
   command.CenterPoint = New LeadPoint(leadImage.Width \ 4, leadImage.Height \ 4)
   command.Brightness = 100
   command.Type = LensFlareCommandType.Type1
   command.Color = New RasterColor(100, 150, 10)
   ' Apply the lens flare effect to the image.
   command.Run(leadImage)
   codecs.Save(leadImage, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24)

End Sub

Public NotInheritable Class LEAD_VARS
   Public Const ImagesDir As String = "C:\Users\Public\Documents\LEADTOOLS Images"
End Class

public void LensFlareCommandExample()
   {
      // Load an image
      RasterCodecs codecs = new RasterCodecs();
      codecs.ThrowExceptionsOnInvalidImages = true;

      RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "Master.jpg"));

      // Prepare the command
      LensFlareCommand command = new LensFlareCommand();
      //Set the center point in the middle of the first square.
      command.CenterPoint = new LeadPoint(image.Width / 4, image.Height / 4);
      command.Brightness = 100;
      command.Type = LensFlareCommandType.Type1;
      command.Color = new RasterColor(100, 150, 10);
      // Apply the lens flare effect to the image.
      command.Run(image);
      codecs.Save(image, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24);

   }

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\Users\Public\Documents\LEADTOOLS Images";
}

[TestMethod]
public async Task LensFlareCommandExample()
{
   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.ThrowExceptionsOnInvalidImages = true;
   string srcFileName = @"Assets\Image1.cmp";
   StorageFile loadFile = await Tools.AppInstallFolder.GetFileAsync(srcFileName);
   RasterImage image = await codecs.LoadAsync(LeadStreamFactory.Create(loadFile));

   // Prepare the command
   LensFlareCommand command = new LensFlareCommand();
   //Set the center point in the middle of the first square.
   command.CenterPoint = LeadPointHelper.Create(image.Width / 4, image.Height / 4);
   command.Brightness = 100;
   command.Type = LensFlareCommandType.Type1;
   command.Color = RasterColorHelper.Create(100, 150, 10);
   // Apply the lens flare effect to the image.
   command.Run(image);

   string destFileName = @"result.bmp";
   StorageFile saveFile = await Tools.AppLocalFolder.CreateFileAsync(destFileName);
   await codecs.SaveAsync(image, LeadStreamFactory.Create(saveFile), RasterImageFormat.Bmp, 24);
}

Requirements

Target Platforms: Windows 7, Windows Vista SP1 or later, Windows XP SP3, Windows Server 2008 (Server Core not supported), Windows Server 2008 R2 (Server Core supported with SP1 or later), Windows Server 2003 SP2

Reference
