Leadtools.Annotations Namespace : AnnPolylineObject Class |
[SerializableAttribute()] public class AnnPolylineObject : AnnObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
'Declaration <SerializableAttribute()> Public Class AnnPolylineObject Inherits AnnObject Implements System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
'Usage Dim instance As AnnPolylineObject
public sealed class AnnPolylineObject : System.ICloneable, IClosable //In WinRT the IDisposable interface is replaced by IClosable, ~Remove~
function Leadtools.Annotations.AnnPolylineObject()
[SerializableAttribute()] public ref class AnnPolylineObject : public AnnObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
The polyline object is a simple polyline that contains a collection of AnnPoint points and a pen. For more information about the polyline annotation object refer to AnnPolylineObject. For more information about the automated polyline annotation object, refer to Annotation Objects - Automated Features.
Private Sub AnnPolylineObject_AnnPolylineObject(ByVal container As AnnContainer) Dim polyline As AnnPolylineObject = New AnnPolylineObject() polyline.Points.Add(New AnnPoint(100, 100, AnnUnit.Pixel)) polyline.Points.Add(New AnnPoint(200, 100, AnnUnit.Pixel)) polyline.Points.Add(New AnnPoint(200, 200, AnnUnit.Pixel)) polyline.Points.Add(New AnnPoint(100, 300, AnnUnit.Pixel)) polyline.Pen = New AnnPen(Color.Red, New AnnLength(1, AnnUnit.Pixel)) container.Objects.Add(polyline) End Sub
private void AnnPolylineObject_AnnPolylineObject(AnnContainer container) { AnnPolylineObject polyline = new AnnPolylineObject(); polyline.Points.Add(new AnnPoint(100, 100, AnnUnit.Pixel)); polyline.Points.Add(new AnnPoint(200, 100, AnnUnit.Pixel)); polyline.Points.Add(new AnnPoint(200, 200, AnnUnit.Pixel)); polyline.Points.Add(new AnnPoint(100, 300, AnnUnit.Pixel)); polyline.Pen = new AnnPen(Color.Red, new AnnLength(1, AnnUnit.Pixel)); container.Objects.Add(polyline); }
Target Platforms: Windows 7, Windows Vista SP1 or later, Windows XP SP3, Windows Server 2008 (Server Core not supported), Windows Server 2008 R2 (Server Core supported with SP1 or later), Windows Server 2003 SP2
