AnnClosedCurveObject Class

Visual Basic
C#
WinRT C#
WinRT JavaScript
C++

[SerializableAttribute()]
public class AnnClosedCurveObject : AnnPolygonObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Declaration

<SerializableAttribute()>
Public Class AnnClosedCurveObject
   Inherits AnnPolygonObject
   Implements System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Usage

Dim instance As AnnClosedCurveObject

public sealed class AnnClosedCurveObject : System.ICloneable, IClosable //In WinRT the IDisposable interface is replaced by IClosable, ~Remove~

function Leadtools.Annotations.AnnClosedCurveObject()

[SerializableAttribute()]
public ref class AnnClosedCurveObject : public AnnPolygonObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

The closed curve object is a spline curve that contains a collection of AnnPoint points, a pen, a brush and a tension value. The curve can be AnnPolygonObject.Closed or not, and can also have a certain AnnPolygonObject.FillMode.

For more information about the closed curve annotation object refer to AnnClosedCurveObject. For more information about the automated closed curve annotation object, refer to Annotation Objects - Automated Features.

Visual Basic
C#
WinRT C#
WinRT JavaScript
Silverlight C#
Silverlight VB

Private Sub AnnClosedCurveObject_AnnClosedCurveObject(ByVal container As AnnContainer)
   Dim closedCurve As AnnClosedCurveObject = New AnnClosedCurveObject()
   closedCurve.Points.Add(New AnnPoint(100, 100, AnnUnit.Pixel))
   closedCurve.Points.Add(New AnnPoint(200, 100, AnnUnit.Pixel))
   closedCurve.Points.Add(New AnnPoint(200, 200, AnnUnit.Pixel))
   closedCurve.Points.Add(New AnnPoint(100, 300, AnnUnit.Pixel))
   closedCurve.Tension = 1
   closedCurve.Pen = New AnnPen(Color.Red, New AnnLength(1, AnnUnit.Pixel))
   closedCurve.Brush = New AnnSolidBrush(Color.White)
   closedCurve.FillMode = FillMode.Alternate
   closedCurve.Closed = True
   container.Objects.Add(closedCurve)
End Sub

private void AnnClosedCurveObject_AnnClosedCurveObject(AnnContainer container)
{
   AnnClosedCurveObject closedCurve = new AnnClosedCurveObject();
   closedCurve.Points.Add(new AnnPoint(100, 100, AnnUnit.Pixel));
   closedCurve.Points.Add(new AnnPoint(200, 100, AnnUnit.Pixel));
   closedCurve.Points.Add(new AnnPoint(200, 200, AnnUnit.Pixel));
   closedCurve.Points.Add(new AnnPoint(100, 300, AnnUnit.Pixel));
   closedCurve.Tension = 1;
   closedCurve.Pen = new AnnPen(Color.Red, new AnnLength(1, AnnUnit.Pixel));
   closedCurve.Brush = new AnnSolidBrush(Color.White);
   closedCurve.FillMode = FillMode.Alternate;
   closedCurve.Closed = true;
   container.Objects.Add(closedCurve);
}

Target Platforms: Windows 7, Windows Vista SP1 or later, Windows XP SP3, Windows Server 2008 (Server Core not supported), Windows Server 2008 R2 (Server Core supported with SP1 or later), Windows Server 2003 SP2
