| Leadtools.Annotations Namespace : AnnPolygonObject Class |
[SerializableAttribute()] public class AnnPolygonObject : AnnPolylineObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
'Declaration <SerializableAttribute()> Public Class AnnPolygonObject Inherits AnnPolylineObject Implements System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
'Usage Dim instance As AnnPolygonObject
public sealed class AnnPolygonObject : System.ICloneable, IClosable //In WinRT the IDisposable interface is replaced by IClosable, ~Remove~
function Leadtools.Annotations.AnnPolygonObject()
[SerializableAttribute()] public ref class AnnPolygonObject : public AnnPolylineObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
The polygon object is a simple polygon that contains a collection of AnnPoint points, a AnnPen pen and a AnnBrush brush. The polygon can be Closed or not, and can also have a certain FillMode. For an illustration of the different fill modes, refer to Illustration of the Polygon Fill Mode for Annotations.
For more information about the polygon annotation object refer to AnnPolygonObject. For more information about the automated polygon annotation object, refer to Annotation Objects - Automated Features.
Private Sub AnnPolygonObject_AnnPolygonObject(ByVal container As AnnContainer) Dim polygon As AnnPolygonObject = New AnnPolygonObject() polygon.Points.Add(New AnnPoint(100, 100, AnnUnit.Pixel)) polygon.Points.Add(New AnnPoint(200, 100, AnnUnit.Pixel)) polygon.Points.Add(New AnnPoint(200, 200, AnnUnit.Pixel)) polygon.Points.Add(New AnnPoint(100, 300, AnnUnit.Pixel)) polygon.Pen = New AnnPen(Color.Red, New AnnLength(1, AnnUnit.Pixel)) polygon.Brush = New AnnSolidBrush(Color.White) polygon.FillMode = FillMode.Alternate polygon.Closed = True container.Objects.Add(polygon) End Sub
private void AnnPolygonObject_AnnPolygonObject(AnnContainer container) { AnnPolygonObject polygon = new AnnPolygonObject(); polygon.Points.Add(new AnnPoint(100, 100, AnnUnit.Pixel)); polygon.Points.Add(new AnnPoint(200, 100, AnnUnit.Pixel)); polygon.Points.Add(new AnnPoint(200, 200, AnnUnit.Pixel)); polygon.Points.Add(new AnnPoint(100, 300, AnnUnit.Pixel)); polygon.Pen = new AnnPen(Color.Red, new AnnLength(1, AnnUnit.Pixel)); polygon.Brush = new AnnSolidBrush(Color.White); polygon.FillMode = FillMode.Alternate; polygon.Closed = true; container.Objects.Add(polygon); }
Target Platforms: Windows 7, Windows Vista SP1 or later, Windows XP SP3, Windows Server 2008 (Server Core not supported), Windows Server 2008 R2 (Server Core supported with SP1 or later), Windows Server 2003 SP2
