| Leadtools.Annotations Namespace : AnnNoteObject Class |
[SerializableAttribute()] public class AnnNoteObject : AnnTextObject, IAnnTextObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
'Declaration <SerializableAttribute()> Public Class AnnNoteObject Inherits AnnTextObject Implements IAnnTextObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
'Usage Dim instance As AnnNoteObject
public sealed class AnnNoteObject : IAnnTextObject, System.ICloneable, IClosable //In WinRT the IDisposable interface is replaced by IClosable, ~Remove~
function Leadtools.Annotations.AnnNoteObject()
[SerializableAttribute()] public ref class AnnNoteObject : public AnnTextObject, IAnnTextObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
The note annotation object is a rectangle with a shadow border and color background (yellow by default). It contains a text string with font properties. The text will wrap on word breaks within the object's specified rectangle. For more information about the note annotation object refer to AnnNoteObject. For more information about the automated note annotation object, refer to Annotation Objects - Automated Features.
Private Sub AnnNoteObject_AnnNoteObject(ByVal container As AnnContainer, ByVal textString As String) Dim note As AnnNoteObject = New AnnNoteObject() note.Text = textString note.Font = New AnnFont("Arial", New AnnLength(10, AnnUnit.Point), FontStyle.Regular) note.EdgeMargin = AnnLength.Empty note.ShadowBorderWidth = New AnnLength(6, AnnUnit.Pixel) note.Alignment = StringAlignment.Center note.LineAlignment = StringAlignment.Center note.Bounds = New AnnRectangle(100, 200, 400, 600, AnnUnit.Pixel) container.Objects.Add(note) End Sub
private void AnnNoteObject_AnnNoteObject(AnnContainer container, string textString) { AnnNoteObject note = new AnnNoteObject(); note.Text = textString; note.Font = new AnnFont("Arial", new AnnLength(10, AnnUnit.Point), FontStyle.Regular); note.EdgeMargin = AnnLength.Empty; note.ShadowBorderWidth = new AnnLength(6, AnnUnit.Pixel); note.Alignment = StringAlignment.Center; note.LineAlignment = StringAlignment.Center; note.Bounds = new AnnRectangle(100, 200, 400, 600, AnnUnit.Pixel); container.Objects.Add(note); }
Target Platforms: Windows 7, Windows Vista SP1 or later, Windows XP SP3, Windows Server 2008 (Server Core not supported), Windows Server 2008 R2 (Server Core supported with SP1 or later), Windows Server 2003 SP2
