LEADTOOLS Raster imaging C++ Class library help

LAnnFreehandHotSpot::GetSecondaryMetafile

Show in webframe

#include "ltwrappr.h"

virtual L_INT LAnnFreehandHotSpot::GetSecondaryMetafile(phMetafile)

HMETAFILE * phMetafile;

/* pointer to a variable to be updated with the handle to a metafile */

Retrieves the metafile handle associated with an FreehandHotSpot object when it is in the decryptor state.

Parameter

Description

phMetafile

Pointer to a variable to be updated with the handle to a metafile.

Returns

SUCCESS

The function was successful.

< 1

An error occurred. Refer to Return Codes.

Comments

The FreehandHotSpot object has two states:

Encryptor

Decryptor

Each state is displayed with its own metafile. Use this function to retrieve the current metafile for an FreehandHotSpot object in a decryptor state. The default image is shown in the figure below:


If this function is successful, the address pointed to by phMetafile will be updated with the metafile handle.

Use the LAnnFreehandHotSpot::GetMetafile function to retrieve the current metafile for an FreehandHotSpot object in an encryptor state.

Required DLLs and Libraries

LTANN

For a listing of the exact DLLs and Libraries needed, based on the toolkit version, refer to Files To Be Included With Your Application.

Platforms

Win32, x64.

See Also

Functions:

Class Members

Topics:

Annotation Functions: Object Properties



Implementing Annotations



Automated User Interface for Annotations



Annotation Functions: Creating and Deleting Annotations



Types of Annotations



Annotation Functions: Implementing Custom Annotations

Example

// This example swaps the metafiles for a FreeHandHotSpot object.

L_INT LAnnFreehandHotSpot_GetSecondaryMetafileExample(LAnnFreehandHotSpot *pLFreehandHotSpot)
{
   L_INT nRet;
   HMETAFILE hMetafile1=0;
   HMETAFILE hMetafile2=0;
   nRet = pLFreehandHotSpot->GetMetafile(&hMetafile1);
   if(nRet != SUCCESS)
      return nRet;
   nRet = pLFreehandHotSpot->GetSecondaryMetafile(&hMetafile2);
   if(nRet != SUCCESS)
      return nRet;
   nRet = pLFreehandHotSpot->SetMetafile(hMetafile2, ANNMETAFILE_USER, 0);
   if(nRet != SUCCESS)
      return nRet;
   return SUCCESS;
}
