| Leadtools.Annotations Namespace : AnnCrossProductObject Class |
[SerializableAttribute()] public class AnnCrossProductObject : AnnObject, IAnnRulerObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
'Declaration <SerializableAttribute()> Public Class AnnCrossProductObject Inherits AnnObject Implements IAnnRulerObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
'Usage Dim instance As AnnCrossProductObject
[SerializableAttribute()] public ref class AnnCrossProductObject : public AnnObject, IAnnRulerObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
The cross-product annotation object consists of two rulers intersecting at right angles. The intersection point of a cross product object updates dynamically and can be obtained through the IntersectionPoint property.
For more information about the crossproduct annotation object refer to AnnCrossProductObject. For more information about the automated crossproduct annotation object, refer to Annotation Objects - Automated Features.
This example creates a cross product object.
Copy Code
Imports Leadtools Imports Leadtools.Annotations Imports Leadtools.Codecs Imports Leadtools.WinForms Private Sub AnnCrossProductObject_AnnCrossProductObject(ByVal container As AnnContainer) Dim crossProduct As AnnCrossProductObject = New AnnCrossProductObject() crossProduct.Pen = New AnnPen(Color.Red, New AnnLength(1, AnnUnit.Pixel)) crossProduct.Font = New AnnFont("Arial", New AnnLength(10, AnnUnit.Point), FontStyle.Regular) crossProduct.FirstStartPoint = New AnnPoint(5, 5, AnnUnit.Inch) crossProduct.FirstEndPoint = New AnnPoint(10, 10, AnnUnit.Inch) ' make this cross product symmetrical crossProduct.UpdateSecondPoints() ' update the intersection point crossProduct.UpdateIntersectionPoint() crossProduct.MeasurementUnit = AnnUnit.Inch crossProduct.TickMarksLength = New AnnLength(0.25F, AnnUnit.Inch) crossProduct.ShowTickMarks = True crossProduct.GaugeLength = New AnnLength(1.0F, AnnUnit.Inch) crossProduct.ShowGauge = True crossProduct.ShowLength = True crossProduct.Precision = 2 container.Objects.Add(crossProduct) ' show the intersection point MessageBox.Show(String.Format("Intersection point is at: {0}", crossProduct.IntersectionPoint)) End Sub
using Leadtools; using Leadtools.Annotations; using Leadtools.Codecs; using Leadtools.WinForms; private void AnnCrossProductObject_AnnCrossProductObject(AnnContainer container) { AnnCrossProductObject crossProduct = new AnnCrossProductObject(); crossProduct.Pen = new AnnPen(Color.Red, new AnnLength(1, AnnUnit.Pixel)); crossProduct.Font = new AnnFont("Arial", new AnnLength(10, AnnUnit.Point), FontStyle.Regular); crossProduct.FirstStartPoint = new AnnPoint(5, 5, AnnUnit.Inch); crossProduct.FirstEndPoint = new AnnPoint(10, 10, AnnUnit.Inch); // make this cross product symmetrical crossProduct.UpdateSecondPoints(); // update the intersection point crossProduct.UpdateIntersectionPoint(); crossProduct.MeasurementUnit = AnnUnit.Inch; crossProduct.TickMarksLength = new AnnLength(0.25F, AnnUnit.Inch); crossProduct.ShowTickMarks = true; crossProduct.GaugeLength = new AnnLength(1.0F, AnnUnit.Inch); crossProduct.ShowGauge = true; crossProduct.ShowLength = true; crossProduct.Precision = 2; container.Objects.Add(crossProduct); // show the intersection point MessageBox.Show(String.Format("Intersection point is at: {0}", crossProduct.IntersectionPoint)); }
