| Leadtools.Annotations Namespace : AnnNoteObject Class |
[SerializableAttribute()] public class AnnNoteObject : AnnTextObject, IAnnTextObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
'Declaration <SerializableAttribute()> Public Class AnnNoteObject Inherits AnnTextObject Implements IAnnTextObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
'Usage Dim instance As AnnNoteObject
[SerializableAttribute()] public ref class AnnNoteObject : public AnnTextObject, IAnnTextObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
The note annotation object is a rectangle with a shadow border and color background (yellow by default). It contains a text string with font properties. The text will wrap on word breaks within the object's specified rectangle. For more information about the note annotation object refer to AnnNoteObject. For more information about the automated note annotation object, refer to Annotation Objects - Automated Features.
This example creates a new note object and then adds it to a container.
Copy Code
Imports Leadtools Imports Leadtools.Annotations Imports Leadtools.Codecs Imports Leadtools.WinForms Private Sub AnnNoteObject_AnnNoteObject(ByVal container As AnnContainer, ByVal textString As String) Dim note As AnnNoteObject = New AnnNoteObject() note.Text = textString note.Font = New AnnFont("Arial", New AnnLength(10, AnnUnit.Point), FontStyle.Regular) note.EdgeMargin = AnnLength.Empty note.ShadowBorderWidth = New AnnLength(6, AnnUnit.Pixel) note.Alignment = StringAlignment.Center note.LineAlignment = StringAlignment.Center note.Bounds = New AnnRectangle(100, 200, 400, 600, AnnUnit.Pixel) container.Objects.Add(note) End Sub
using Leadtools; using Leadtools.Annotations; using Leadtools.Codecs; using Leadtools.WinForms; private void AnnNoteObject_AnnNoteObject(AnnContainer container, string textString) { AnnNoteObject note = new AnnNoteObject(); note.Text = textString; note.Font = new AnnFont("Arial", new AnnLength(10, AnnUnit.Point), FontStyle.Regular); note.EdgeMargin = AnnLength.Empty; note.ShadowBorderWidth = new AnnLength(6, AnnUnit.Pixel); note.Alignment = StringAlignment.Center; note.LineAlignment = StringAlignment.Center; note.Bounds = new AnnRectangle(100, 200, 400, 600, AnnUnit.Pixel); container.Objects.Add(note); }
