| Leadtools.Annotations Namespace : AnnPolylineObject Class |
[SerializableAttribute()] public class AnnPolylineObject : AnnObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
'Declaration <SerializableAttribute()> Public Class AnnPolylineObject Inherits AnnObject Implements System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
'Usage Dim instance As AnnPolylineObject
[SerializableAttribute()] public ref class AnnPolylineObject : public AnnObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
The polyline object is a simple polyline that contains a collection of AnnPoint points and a pen. For more information about the polyline annotation object refer to AnnPolylineObject. For more information about the automated polyline annotation object, refer to Annotation Objects - Automated Features.
This example creates a new polyline object with 4 points.
Copy Code
Imports Leadtools Imports Leadtools.Annotations Imports Leadtools.Codecs Imports Leadtools.WinForms Private Sub AnnPolylineObject_AnnPolylineObject(ByVal container As AnnContainer) Dim polyline As AnnPolylineObject = New AnnPolylineObject() polyline.Points.Add(New AnnPoint(100, 100, AnnUnit.Pixel)) polyline.Points.Add(New AnnPoint(200, 100, AnnUnit.Pixel)) polyline.Points.Add(New AnnPoint(200, 200, AnnUnit.Pixel)) polyline.Points.Add(New AnnPoint(100, 300, AnnUnit.Pixel)) polyline.Pen = New AnnPen(Color.Red, New AnnLength(1, AnnUnit.Pixel)) container.Objects.Add(polyline) End Sub
using Leadtools; using Leadtools.Annotations; using Leadtools.Codecs; using Leadtools.WinForms; private void AnnPolylineObject_AnnPolylineObject(AnnContainer container) { AnnPolylineObject polyline = new AnnPolylineObject(); polyline.Points.Add(new AnnPoint(100, 100, AnnUnit.Pixel)); polyline.Points.Add(new AnnPoint(200, 100, AnnUnit.Pixel)); polyline.Points.Add(new AnnPoint(200, 200, AnnUnit.Pixel)); polyline.Points.Add(new AnnPoint(100, 300, AnnUnit.Pixel)); polyline.Pen = new AnnPen(Color.Red, new AnnLength(1, AnnUnit.Pixel)); container.Objects.Add(polyline); }
