AnnRedactionObject Class

C#
Visual Basic
Objective-C
Java
C++

[SerializableAttribute()]
public class AnnRedactionObject : AnnRectangleObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Declaration

<SerializableAttribute()>
Public Class AnnRedactionObject
   Inherits AnnRectangleObject
   Implements System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Usage

Dim instance As AnnRedactionObject

[SerializableAttribute()]
public ref class AnnRedactionObject : public AnnRectangleObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

The redaction annotation object is a rectangle with default properties that are appropriate for blacking out an area. The Realize(RasterImageViewer) method lets you block the area on the image with the current object brush value. The Restore(RasterImageViewer) method lets you restore the area back. For more information about the redaction annotation object refer to AnnRedactionObject. For more information about the automated redaction annotation object, refer to Annotation Objects - Automated Features.

If you are interested in locking an object, refer to Implementing Annotation Security.

This example creates a new redaction object, and then addes it to the container.

C#
Visual Basic
WinRT C#
WinRT JavaScript
Silverlight C#
Silverlight VB

Copy Code

Imports Leadtools
Imports Leadtools.Annotations
Imports Leadtools.Codecs
Imports Leadtools.WinForms

Private Sub AnnRedactionObject_AnnRedactionObject(ByVal viewer As RasterImageViewer, ByVal container As AnnContainer)
   Dim redaction As AnnRedactionObject = New AnnRedactionObject()
   redaction.Bounds = New AnnRectangle(100, 100, 300, 300, AnnUnit.Pixel)
   container.Objects.Add(redaction)
   viewer.Invalidate(redaction.InvalidRectangle)
   MessageBox.Show(String.Format("Added. IsRealized: {0}, Objects in container: {1}", redaction.IsRealized, container.Objects.Count))

   ' realize the redaction object
   redaction.Realize(viewer)

   viewer.Invalidate(redaction.InvalidRectangle)
   MessageBox.Show(String.Format("Realized. IsRealized: {0}, Objects in container: {1}", redaction.IsRealized, container.Objects.Count))

   ' remove the redaction object from the container
   container.Objects.Remove(redaction)
   viewer.Invalidate()
   MessageBox.Show(String.Format("Removed. Objects in container: {0}", container.Objects.Count))

   ' add the redaction object back
   container.Objects.Add(redaction)
   viewer.Invalidate(redaction.InvalidRectangle)
   MessageBox.Show(String.Format("Added back. IsRealized: {0}, Objects in container: {1}", redaction.IsRealized, container.Objects.Count))

   ' restore the redaction object
   redaction.Restore(viewer)
   viewer.Invalidate(redaction.InvalidRectangle)
   MessageBox.Show(String.Format("Restored. IsRealized: {0}, Objects in container: {1}", redaction.IsRealized, container.Objects.Count))

   ' remove the redaction again from the container
   container.Objects.Remove(redaction)
   viewer.Invalidate()
   MessageBox.Show(String.Format("Removed. Objects in container: {0}", container.Objects.Count))
End Sub

using Leadtools;
using Leadtools.Annotations;
using Leadtools.Codecs;
using Leadtools.WinForms;

private void AnnRedactionObject_AnnRedactionObject(RasterImageViewer viewer, AnnContainer container)
{
   AnnRedactionObject redaction = new AnnRedactionObject();
   redaction.Bounds = new AnnRectangle(100, 100, 300, 300, AnnUnit.Pixel);
   container.Objects.Add(redaction);
   viewer.Invalidate(redaction.InvalidRectangle);
   MessageBox.Show(String.Format("Added. IsRealized: {0}, Objects in container: {1}", redaction.IsRealized, container.Objects.Count));

   // realize the redaction object
   redaction.Realize(viewer);

   viewer.Invalidate(redaction.InvalidRectangle);
   MessageBox.Show(String.Format("Realized. IsRealized: {0}, Objects in container: {1}", redaction.IsRealized, container.Objects.Count));

   // remove the redaction object from the container
   container.Objects.Remove(redaction);
   viewer.Invalidate();
   MessageBox.Show(String.Format("Removed. Objects in container: {0}", container.Objects.Count));

   // add the redaction object back
   container.Objects.Add(redaction);
   viewer.Invalidate(redaction.InvalidRectangle);
   MessageBox.Show(String.Format("Added back. IsRealized: {0}, Objects in container: {1}", redaction.IsRealized, container.Objects.Count));

   // restore the redaction object
   redaction.Restore(viewer);
   viewer.Invalidate(redaction.InvalidRectangle);
   MessageBox.Show(String.Format("Restored. IsRealized: {0}, Objects in container: {1}", redaction.IsRealized, container.Objects.Count));

   // remove the redaction again from the container
   container.Objects.Remove(redaction);
   viewer.Invalidate();
   MessageBox.Show(String.Format("Removed. Objects in container: {0}", container.Objects.Count));
}
