FreePlaneBendCommandBitmapEffect Class
See Also  Members
Leadtools.Windows.Media.Effects.SpecialEffects Namespace : FreePlaneBendCommandBitmapEffect Class




Wraps the image onto a 3D plane shaped by Curve. This command is available in the Raster Pro and above toolkits.

Syntax

Visual Basic (Declaration)
Public Class FreePlaneBendCommandBitmapEffect
   Inherits RasterCommandBitmapEffect
Visual Basic (Usage)Copy Code
Dim instance As FreePlaneBendCommandBitmapEffect
C#
public class FreePlaneBendCommandBitmapEffect : RasterCommandBitmapEffect
Managed Extensions for C++
public __gc class FreePlaneBendCommandBitmapEffect : public RasterCommandBitmapEffect
C++/CLI
public ref class FreePlaneBendCommandBitmapEffect : public RasterCommandBitmapEffect

Remarks

  • For an example, the following figure shows an image before the effect is applied.

    The following figure shows the same image after the effect has been applied.
  • This command supports 12 and 16-bit grayscale and 48 and 64-bit color images. Support for 12 and 16-bit grayscale and 48 and 64-bit color images is available only in the Document/Medical toolkits.
  • This command does not support signed data images.
  • This command does not support 32-bit grayscale images.

Inheritance Hierarchy

System.Object
   System.Windows.Threading.DispatcherObject
      System.Windows.DependencyObject
         System.Windows.Freezable
            System.Windows.Media.Animation.Animatable
               System.Windows.Media.Effects.BitmapEffect
                  Leadtools.Windows.Media.Effects.RasterCommandBitmapEffect
                     Leadtools.Windows.Media.Effects.SpecialEffects.FreePlaneBendCommandBitmapEffect

Requirements

Target Platforms: Microsoft .NET Framework 2.0, Windows 98, Windows NT 4.0, Windows Millennium Edition, Windows 2000, Windows XP Home Edition, Windows XP Professional, Windows Server 2003 family
