AnnPointObject Class

Visual Basic
C#
WinRT C#
WinRT JavaScript
C++

[SerializableAttribute()]
public class AnnPointObject : AnnObject, IAnnPictureObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Declaration

<SerializableAttribute()>
Public Class AnnPointObject
   Inherits AnnObject
   Implements IAnnPictureObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Usage

Dim instance As AnnPointObject

public sealed class AnnPointObject : IAnnPictureObject, System.ICloneable, IClosable //In WinRT the IDisposable interface is replaced by IClosable, ~Remove~

function Leadtools.Annotations.AnnPointObject()

[SerializableAttribute()]
public ref class AnnPointObject : public AnnObject, IAnnPictureObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

The point object is a single point. This object works in two ways: If the value of ShowPicture is true; this object will draw the picture in Picture with CenterPoint as the center point. AnnDrawable.Pen, AnnDrawable.Brush and Radius will be ignored. If ShowPicture is false; this object will draw an ellipse using AnnDrawable.Pen, AnnDrawable.Brush and Radius around CenterPoint.

This class implements the IAnnPictureObject interface and accesses the IAnnPictureObject.Picture property that handles the picture associated with the annotation object.

For more information, refer to Using Pictures in Annotation Objects

For more information about the point annotation object refer to AnnPointObject. For more information about the automated point annotation object, refer to Annotation Objects - Automated Features and Automated Annotations - Point Tab.

Visual Basic
C#
WinRT C#
WinRT JavaScript
Silverlight C#
Silverlight VB

Private Sub AnnPointObject_AnnPointObject(ByVal viewer As RasterImageViewer, ByVal container As AnnContainer)
   Dim point As AnnPointObject = New AnnPointObject()
   point.CenterPoint = New AnnPoint(100, 100, AnnUnit.Pixel)
   point.ShowPicture = True
   ' default picture, no need to change anything
   container.Objects.Add(point)
   viewer.Invalidate(point.InvalidRectangle)
   MessageBox.Show("Picture")

   ' show with a radius
   point.Radius = New AnnLength(16, AnnUnit.Pixel)
   point.Pen = New AnnPen(Color.Red, New AnnLength(1, AnnUnit.Pixel))
   point.ShowPicture = False
   viewer.Invalidate(point.InvalidRectangle)
   MessageBox.Show("No picture")
End Sub

private void AnnPointObject_AnnPointObject(RasterImageViewer viewer, AnnContainer container)
{
   AnnPointObject point = new AnnPointObject();
   point.CenterPoint = new AnnPoint(100, 100, AnnUnit.Pixel);
   point.ShowPicture = true;
   // default picture, no need to change anything
   container.Objects.Add(point);
   viewer.Invalidate(point.InvalidRectangle);
   MessageBox.Show("Picture");

   // show with a radius
   point.Radius = new AnnLength(16, AnnUnit.Pixel);
   point.Pen = new AnnPen(Color.Red, new AnnLength(1, AnnUnit.Pixel));
   point.ShowPicture = false;
   viewer.Invalidate(point.InvalidRectangle);
   MessageBox.Show("No picture");
}

Target Platforms: Windows 7, Windows Vista SP1 or later, Windows XP SP3, Windows Server 2008 (Server Core not supported), Windows Server 2008 R2 (Server Core supported with SP1 or later), Windows Server 2003 SP2
