LEADTOOLS Annotations (Leadtools.Annotations assembly)
Send comments on this topic. | Back to Introduction - All Topics | Help Version 17.5.11.1
| Leadtools.Annotations Namespace : AnnEllipseObject Class |
[SerializableAttribute()] public class AnnEllipseObject : AnnRectangleObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
'Declaration <SerializableAttribute()> Public Class AnnEllipseObject Inherits AnnRectangleObject Implements System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
'Usage Dim instance As AnnEllipseObject
public sealed class AnnEllipseObject : System.ICloneable, IClosable //In WinRT the IDisposable interface is replaced by IClosable, ~Remove~
function Leadtools.Annotations.AnnEllipseObject()
[SerializableAttribute()] public ref class AnnEllipseObject : public AnnRectangleObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
The ellipse annotation object is a simple ellipse defined by a bounding rectangle, a pen and a brush.
For more information about the ellipse annotation object refer to AnnEllipseObject. For more information about the automated ellipse annotation object, refer to Annotation Objects - Automated Features.
Private Sub AnnEllipseObject_AnnEllipseObject(ByVal container As AnnContainer) Dim ellipse As AnnEllipseObject = New AnnEllipseObject() ellipse.Pen = New AnnPen(Color.Red, New AnnLength(1, AnnUnit.Pixel)) ellipse.Brush = New AnnSolidBrush(Color.White) ellipse.Bounds = New AnnRectangle(100, 200, 400, 600, AnnUnit.Pixel) container.Objects.Add(ellipse) End Sub
private void AnnEllipseObject_AnnEllipseObject(AnnContainer container) { AnnEllipseObject ellipse = new AnnEllipseObject(); ellipse.Pen = new AnnPen(Color.Red, new AnnLength(1, AnnUnit.Pixel)); ellipse.Brush = new AnnSolidBrush(Color.White); ellipse.Bounds = new AnnRectangle(100, 200, 400, 600, AnnUnit.Pixel); container.Objects.Add(ellipse); }
Target Platforms: Windows 7, Windows Vista SP1 or later, Windows XP SP3, Windows Server 2008 (Server Core not supported), Windows Server 2008 R2 (Server Core supported with SP1 or later), Windows Server 2003 SP2
