DiffuseGlowCommand Class

Visual Basic
C#
WinRT C#
WinRT JavaScript
C++

public class DiffuseGlowCommand : Leadtools.ImageProcessing.RasterCommand, Leadtools.ImageProcessing.IRasterCommand

'Declaration

Public Class DiffuseGlowCommand
   Inherits Leadtools.ImageProcessing.RasterCommand
   Implements Leadtools.ImageProcessing.IRasterCommand

'Usage

Dim instance As DiffuseGlowCommand

public sealed class DiffuseGlowCommand : Leadtools.ImageProcessing.IRasterCommand

function Leadtools.ImageProcessing.SpecialEffects.DiffuseGlowCommand()

public ref class DiffuseGlowCommand : public Leadtools.ImageProcessing.RasterCommand, Leadtools.ImageProcessing.IRasterCommand

This command adds pixels randomly to the image. A glow is added based on a combination of the pixel colors and the glow color.

As an example, if you use the following image:

And you were to call DiffuseGlowCommand using the following settings:

Parameter	Value
GlowAmount	50
ClearAmount	50
SpreadAmount	10
WhiteNoiseRange	10
GlowColor	white

The following figure results:

If the image has a region, the effect will be applied on the region only.
This method supports 12- and 16-bit grayscale and 48- and 64-bit color images. Support for 12- and 16-bit grayscale and 48- and 64-bit color images is available only in the Document/Medical toolkits.
This method does not support signed data images.
This command does not support 32-bit grayscale images.

For more information, refer to Removing Noise.

Visual Basic
C#
WinRT C#
WinRT JavaScript
Silverlight C#
Silverlight VB

Public Sub DiffuseGlowCommandExample()
   Dim codecs As New RasterCodecs()
   codecs.ThrowExceptionsOnInvalidImages = True

   Dim leadImage As RasterImage = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "Master.jpg"))

   ' Prepare the command
   Dim fillColor As New RasterColor(255, 255, 255)
   Dim command As New DiffuseGlowCommand
   command.GlowAmount = 50
   command.ClearAmount = 50
   command.SpreadAmount = 10
   command.WhiteNoiseRange = 10
   command.GlowColor = fillColor
   command.Run(leadImage)
   codecs.Save(leadImage, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24)

End Sub

Public NotInheritable Class LEAD_VARS
   Public Const ImagesDir As String = "C:\Users\Public\Documents\LEADTOOLS Images"
End Class

public void DiffuseGlowCommandExample()
   {
      // Load an image
      RasterCodecs codecs = new RasterCodecs();
      codecs.ThrowExceptionsOnInvalidImages = true;

      RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "Master.jpg"));

      // Prepare the command
      RasterColor fillColor = new RasterColor(255, 255, 255);
      DiffuseGlowCommand command = new DiffuseGlowCommand () ;
      command.GlowAmount = 50;
      command.ClearAmount = 50;
      command.SpreadAmount = 10;
      command.WhiteNoiseRange = 10;
      command.GlowColor = fillColor;
      command.Run(image);
      codecs.Save(image, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24);

   }

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\Users\Public\Documents\LEADTOOLS Images";
}

[TestMethod]
public async Task DiffuseGlowCommandExample()
{
   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.ThrowExceptionsOnInvalidImages = true;
   string srcFileName = @"Assets\Image1.cmp";
   StorageFile loadFile = await Tools.AppInstallFolder.GetFileAsync(srcFileName);
   RasterImage image = await codecs.LoadAsync(LeadStreamFactory.Create(loadFile));

   // Prepare the command
   RasterColor fillColor = RasterColorHelper.Create(255, 255, 255);
   DiffuseGlowCommand command = new DiffuseGlowCommand () ;
   command.GlowAmount = 50;
   command.ClearAmount = 50;
   command.SpreadAmount = 10;
   command.WhiteNoiseRange = 10;
   command.GlowColor = fillColor;
   command.Run(image);

   string destFileName = @"result.bmp";
   StorageFile saveFile = await Tools.AppLocalFolder.CreateFileAsync(destFileName);
   await codecs.SaveAsync(image, LeadStreamFactory.Create(saveFile), RasterImageFormat.Bmp, 24);
}

Target Platforms: Windows 7, Windows Vista SP1 or later, Windows XP SP3, Windows Server 2008 (Server Core not supported), Windows Server 2008 R2 (Server Core supported with SP1 or later), Windows Server 2003 SP2

Reference
