AnnPolylineObject Class

Visual Basic
C#
Objective-C
Java
C++

[SerializableAttribute()]
public class AnnPolylineObject : AnnObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Declaration

<SerializableAttribute()>
Public Class AnnPolylineObject
   Inherits AnnObject
   Implements System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Usage

Dim instance As AnnPolylineObject

[SerializableAttribute()]
public ref class AnnPolylineObject : public AnnObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

The polyline object is a simple polyline that contains a collection of AnnPoint points and a pen. For more information about the polyline annotation object refer to AnnPolylineObject. For more information about the automated polyline annotation object, refer to Annotation Objects - Automated Features.

Visual Basic
C#
WinRT C#
WinRT JavaScript
Silverlight C#
Silverlight VB

Copy Code

Imports Leadtools
Imports Leadtools.Annotations
Imports Leadtools.Codecs
Imports Leadtools.WinForms

Private Sub AnnPolylineObject_AnnPolylineObject(ByVal container As AnnContainer)
   Dim polyline As AnnPolylineObject = New AnnPolylineObject()
   polyline.Points.Add(New AnnPoint(100, 100, AnnUnit.Pixel))
   polyline.Points.Add(New AnnPoint(200, 100, AnnUnit.Pixel))
   polyline.Points.Add(New AnnPoint(200, 200, AnnUnit.Pixel))
   polyline.Points.Add(New AnnPoint(100, 300, AnnUnit.Pixel))
   polyline.Pen = New AnnPen(Color.Red, New AnnLength(1, AnnUnit.Pixel))
   container.Objects.Add(polyline)
End Sub

using Leadtools;
using Leadtools.Annotations;
using Leadtools.Codecs;
using Leadtools.WinForms;

private void AnnPolylineObject_AnnPolylineObject(AnnContainer container)
{
   AnnPolylineObject polyline = new AnnPolylineObject();
   polyline.Points.Add(new AnnPoint(100, 100, AnnUnit.Pixel));
   polyline.Points.Add(new AnnPoint(200, 100, AnnUnit.Pixel));
   polyline.Points.Add(new AnnPoint(200, 200, AnnUnit.Pixel));
   polyline.Points.Add(new AnnPoint(100, 300, AnnUnit.Pixel));
   polyline.Pen = new AnnPen(Color.Red, new AnnLength(1, AnnUnit.Pixel));
   container.Objects.Add(polyline);
}
