AnnRectangleObject Class

Visual Basic
C#
Objective-C
Java
C++

[SerializableAttribute()]
public class AnnRectangleObject : AnnObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Declaration

<SerializableAttribute()>
Public Class AnnRectangleObject
   Inherits AnnObject
   Implements System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Usage

Dim instance As AnnRectangleObject

[SerializableAttribute()]
public ref class AnnRectangleObject : public AnnObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

The rectangle annotation object is a simple rectangle that has a bounding rectangle, a pen and a brush. For more information about the rectangle annotation object refer to AnnRectangleObject. For more information about the automated rectangle annotation object, refer to Annotation Objects - Automated Features.

Visual Basic
C#
WinRT C#
WinRT JavaScript
Silverlight C#
Silverlight VB

Copy Code

Imports Leadtools
Imports Leadtools.Annotations
Imports Leadtools.Codecs
Imports Leadtools.WinForms

Private Sub AnnRectangleObject_AnnRectangleObject(ByVal container As AnnContainer)
   Dim rect As AnnRectangleObject = New AnnRectangleObject()
   rect.Pen = New AnnPen(Color.Red, New AnnLength(1, AnnUnit.Pixel))
   rect.Brush = New AnnSolidBrush(Color.White)
   rect.Bounds = New AnnRectangle(100, 200, 400, 600, AnnUnit.Pixel)
   container.Objects.Add(rect)
End Sub

using Leadtools;
using Leadtools.Annotations;
using Leadtools.Codecs;
using Leadtools.WinForms;

private void AnnRectangleObject_AnnRectangleObject(AnnContainer container)
{
   AnnRectangleObject rect = new AnnRectangleObject();
   rect.Pen = new AnnPen(Color.Red, new AnnLength(1, AnnUnit.Pixel));
   rect.Brush = new AnnSolidBrush(Color.White);
   rect.Bounds = new AnnRectangle(100, 200, 400, 600, AnnUnit.Pixel);
   container.Objects.Add(rect);
}

Target Platforms

Reference

AnnRectangleObject Members
Leadtools.Annotations Namespace
