AnnVideoObject Class

Visual Basic
C#
Objective-C
Java
C++

[SerializableAttribute()]
public class AnnVideoObject : AnnImageObject, IAnnPictureObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Declaration

<SerializableAttribute()>
Public Class AnnVideoObject
   Inherits AnnImageObject
   Implements IAnnPictureObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Usage

Dim instance As AnnVideoObject

[SerializableAttribute()]
public ref class AnnVideoObject : public AnnImageObject, IAnnPictureObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

The video annotation object is a scaled image that can be activated to play a video clip. The video file path is stored in the FileName property, so the video data itself is not stored in this object, only the physical path. In run mode, when this video object is clicked, the framework will try to locate and then play the video file stored in FileName. This object will use the default image of a video icon. To change this default image, change the Picture value.

The AnnVideoObject class inherits the the AnnImageObject class and accesses the common Picture property mentioned above through this inheritance.

LEADTOOLS Annotations uses the LEADTOOLS Multimedia for .NET toolkit to render video files and Leadtools.Multimedia must be present on the machine. For more information, refer to Introduction to LEADTOOLS Multimedia for .NET.

For more information about the video annotation object refer to AnnVideoObject.

For more information about the automated annotation video object, refer to Annotation Objects - Automated Features and Automated Annotations - Video Tab.

Visual Basic
C#
WinRT C#
WinRT JavaScript
Silverlight C#
Silverlight VB

Copy Code

Imports Leadtools
Imports Leadtools.Annotations
Imports Leadtools.Codecs
Imports Leadtools.WinForms

Private Sub AnnVideoObject_AnnVideoObject(ByVal container As AnnContainer, ByVal videoFileName As String)
   Dim video As New AnnVideoObject()
   video.Bounds = New AnnRectangle(100, 200, 400, 600, AnnUnit.Pixel)
   video.FileName = videoFileName
   container.Objects.Add(video)
End Sub

using Leadtools;
using Leadtools.Annotations;
using Leadtools.Codecs;
using Leadtools.WinForms;

private void AnnVideoObject_AnnVideoObject(AnnContainer container, string videoFileName)
{
   AnnVideoObject video = new AnnVideoObject();
   video.Bounds = new AnnRectangle(100, 200, 400, 600, AnnUnit.Pixel);
   video.FileName = videoFileName;
   container.Objects.Add(video);
}

Target Platforms

Reference

AnnVideoObject Members
Leadtools.Annotations Namespace
