AnnImageObject Class

C#
Visual Basic
Objective-C
Java
C++

[SerializableAttribute()]
public class AnnImageObject : AnnRectangleObject, IAnnPictureObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Declaration

<SerializableAttribute()>
Public Class AnnImageObject
   Inherits AnnRectangleObject
   Implements IAnnPictureObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Usage

Dim instance As AnnImageObject

[SerializableAttribute()]
public ref class AnnImageObject : public AnnRectangleObject, IAnnPictureObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

The image annotation object is a raster image defined by a bounding rectangle. This object does not support pens or brushes.

The AnnAudioObject and the AnnHotspotObject classes inherit the AnnImageObject class and access the common Picture property through this inheritance. For more information, refer to Using Pictures in Annotation Objects

This example creates a new image object with top, left at 100, 200, width, height of 400, 600 pixels and then adds it to a container.

C#
Visual Basic
WinRT C#
WinRT JavaScript
Silverlight C#
Silverlight VB

Copy Code

Imports Leadtools
Imports Leadtools.Annotations
Imports Leadtools.Codecs
Imports Leadtools.WinForms

Private Sub AnnImageObject_AnnImageObject(ByVal container As AnnContainer, ByVal imageFileName As String)
   Dim img As AnnImageObject = New AnnImageObject()
   Dim pic As AnnPicture = New AnnPicture(Image.FromFile(imageFileName))
   pic.TransparentMode = AnnPictureTransparentMode.None
   pic.TransparentColor = Color.Black
   img.Picture = pic
   img.Bounds = New AnnRectangle(100, 200, 400, 600, AnnUnit.Pixel)
   container.Objects.Add(img)
End Sub

using Leadtools;
using Leadtools.Annotations;
using Leadtools.Codecs;
using Leadtools.WinForms;

private void AnnImageObject_AnnImageObject(AnnContainer container, string imageFileName)
{
   AnnImageObject img = new AnnImageObject();
   AnnPicture pic = new AnnPicture(Image.FromFile(imageFileName));
   pic.TransparentMode = AnnPictureTransparentMode.None;
   pic.TransparentColor = Color.Black;
   img.Picture = pic;
   img.Bounds = new AnnRectangle(100, 200, 400, 600, AnnUnit.Pixel);
   container.Objects.Add(img);
}

Target Platforms

Reference

AnnImageObject Members
Leadtools.Annotations Namespace
