| Leadtools.Annotations Namespace : AnnPointerObject Class |
[SerializableAttribute()] public class AnnPointerObject : AnnLineObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
'Declaration <SerializableAttribute()> Public Class AnnPointerObject Inherits AnnLineObject Implements System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
'Usage Dim instance As AnnPointerObject
[SerializableAttribute()] public ref class AnnPointerObject : public AnnLineObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
The pointer annotation object is defined by two points, with an arrow at the first point. For more information about the pointer annotation object refer to AnnPointerObject. For more information about the automated pointer annotation object, refer to Annotation Objects - Automated Features.
This example adds a new pointer object to a container.
Copy Code
Imports Leadtools Imports Leadtools.Annotations Imports Leadtools.Codecs Imports Leadtools.WinForms Private Sub AnnPointerObject_AnnPointerObject(ByVal container As AnnContainer) Dim pointer As AnnPointerObject = New AnnPointerObject() pointer.Pen = New AnnPen(Color.Red, New AnnLength(1, AnnUnit.Pixel)) pointer.StartPoint = New AnnPoint(100, 100, AnnUnit.Pixel) pointer.EndPoint = New AnnPoint(200, 200, AnnUnit.Pixel) container.Objects.Add(pointer) End Sub
using Leadtools; using Leadtools.Annotations; using Leadtools.Codecs; using Leadtools.WinForms; private void AnnPointerObject_AnnPointerObject(AnnContainer container) { AnnPointerObject pointer = new AnnPointerObject(); pointer.Pen = new AnnPen(Color.Red, new AnnLength(1, AnnUnit.Pixel)); pointer.StartPoint = new AnnPoint(100, 100, AnnUnit.Pixel); pointer.EndPoint = new AnnPoint(200, 200, AnnUnit.Pixel); container.Objects.Add(pointer); }
