ContrastBrightnessIntensityCommand Class

Summary
Applies contrast, brightness and intensity adjustments to enhance the image tonal range. This class is available in the Imaging Pro and above toolkits.
Syntax
C#
Objective-C
C++/CLI
Java
Python
public class ContrastBrightnessIntensityCommand : RasterCommand
@interface LTContrastBrightnessIntensityCommand : LTRasterCommand
public class ContrastBrightnessIntensityCommand
    extends RasterCommand
public ref class ContrastBrightnessIntensityCommand : public RasterCommand
class ContrastBrightnessIntensityCommand(RasterCommand):
Remarks
  • The transformations are applied in this order: Contrast, Brightness then Intensity. Were the three commands to be called separately, then after each method was applied calculated values less than 0 and more than 255 (for 8 bits per component for example) would be clamped to 0 and 255 respectively. Using this method, the values are accumulative and the final result would be clamped. In addition, this command is faster than calling each method separately.
  • It also can process the whole image or a region of the image. If an image has a region, the effect is applied only to the region.
  • This command supports 12 and 16-bit grayscale and 48 and 64-bit color images. Support for 12 and 16-bit grayscale and 48 and 64-bit color images is available only in the Document/Medical toolkits.
  • This command does not support signed data images.
  • This command does not support 32-bit grayscale images.

For more information, refer to Changing Brightness and Contrast.

Contrast Brightness Intensity Function - Before

Contrast Brightness Intensity Function - Before

Contrast Brightness Intensity Function - After

Contrast Brightness Intensity Function - After

View additional platform support for this Contrast Brightness Intensity function.

Example

Run the ContrastBrightnessIntensityCommand on an image.

C#
using Leadtools;
using Leadtools.Codecs;
using Leadtools.ImageProcessing.Color;


public void ContrastBrightnessIntensityCommandExample()
{
   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.ThrowExceptionsOnInvalidImages = true;

   RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "IMAGE1.CMP"));

   // Prepare the command
   ContrastBrightnessIntensityCommand command = new ContrastBrightnessIntensityCommand();
   command.Contrast = -146;
   command.Brightness = 358;
   command.Intensity = 240;
   command.Run(image);
   codecs.Save(image, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24);

}

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\LEADTOOLS22\Resources\Images";
}
Requirements

Target Platforms
