DiffuseGlowCommandBitmapEffect Class
See Also  Members
Leadtools.Windows.Media.Effects.SpecialEffects Namespace : DiffuseGlowCommandBitmapEffect Class




Adds a colored glow to an image's light or dark areas, making these areas shine with a neon glow. This method is available in the Raster Pro and above toolkits

Syntax

Visual Basic (Declaration)
Public Class DiffuseGlowCommandBitmapEffect
   Inherits RasterCommandBitmapEffect
Visual Basic (Usage)Copy Code
Dim instance As DiffuseGlowCommandBitmapEffect
C#
public class DiffuseGlowCommandBitmapEffect : RasterCommandBitmapEffect
Managed Extensions for C++
public __gc class DiffuseGlowCommandBitmapEffect : public RasterCommandBitmapEffect
C++/CLI
public ref class DiffuseGlowCommandBitmapEffect : public RasterCommandBitmapEffect

Remarks

  • This command adds pixels randomly to the image. A glow is added based on a combination of the pixel colors and the glow color.
  • As an example, if you use the following image:

    And you were to call DiffuseGlowCommand using the following settings:
    Parameter Value
    GlowAmount 50
    ClearAmount 50
    SpreadAmount 10
    WhiteNoiseRange 10
    GlowColor white

    The following figure results:
  • This method supports 12- and 16-bit grayscale and 48- and 64-bit color images. Support for 12- and 16-bit grayscale and 48- and 64-bit color images is available only in the Document/Medical toolkits.
  • This method does not support signed data images.
  • This command does not support 32-bit grayscale images.

Inheritance Hierarchy

System.Object
   System.Windows.Threading.DispatcherObject
      System.Windows.DependencyObject
         System.Windows.Freezable
            System.Windows.Media.Animation.Animatable
               System.Windows.Media.Effects.BitmapEffect
                  Leadtools.Windows.Media.Effects.RasterCommandBitmapEffect
                     Leadtools.Windows.Media.Effects.SpecialEffects.DiffuseGlowCommandBitmapEffect

Requirements

Target Platforms: Microsoft .NET Framework 2.0, Windows 98, Windows NT 4.0, Windows Millennium Edition, Windows 2000, Windows XP Home Edition, Windows XP Professional, Windows Server 2003 family
