AnnImageObject Class

[SerializableAttribute()]
public class AnnImageObject : AnnRectangleObject, IAnnPictureObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

public sealed class AnnImageObject : IAnnPictureObject, System.ICloneable, IClosable //In WinRT the IDisposable interface is replaced by IClosable, ~Remove~

function Leadtools.Annotations.AnnImageObject()

[SerializableAttribute()]
public ref class AnnImageObject : public AnnRectangleObject, IAnnPictureObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Declaration

<SerializableAttribute()>
Public Class AnnImageObject
   Inherits AnnRectangleObject
   Implements IAnnPictureObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Usage

Dim instance As AnnImageObject

The image annotation object is a raster image defined by a bounding rectangle. This object does not support pens or brushes.

The AnnAudioObject and the AnnHotspotObject classes inherit the AnnImageObject class and access the common Picture property through this inheritance. For more information, refer to Using Pictures in Annotation Objects

Visual Basic
C#

Private Sub AnnImageObject_AnnImageObject(ByVal container As AnnContainer, ByVal imageFileName As String)
   Dim img As AnnImageObject = New AnnImageObject()
   Dim pic As AnnPicture = New AnnPicture(Image.FromFile(imageFileName))
   pic.TransparentMode = AnnPictureTransparentMode.None
   pic.TransparentColor = Color.Black
   img.Picture = pic
   img.Bounds = New AnnRectangle(100, 200, 400, 600, AnnUnit.Pixel)
   container.Objects.Add(img)
End Sub

private void AnnImageObject_AnnImageObject(AnnContainer container, string imageFileName)
{
   AnnImageObject img = new AnnImageObject();
   AnnPicture pic = new AnnPicture(Image.FromFile(imageFileName));
   pic.TransparentMode = AnnPictureTransparentMode.None;
   pic.TransparentColor = Color.Black;
   img.Picture = pic;
   img.Bounds = new AnnRectangle(100, 200, 400, 600, AnnUnit.Pixel);
   container.Objects.Add(img);
}

Target Platforms: Windows 7, Windows Vista SP1 or later, Windows XP SP3, Windows Server 2008 (Server Core not supported), Windows Server 2008 R2 (Server Core supported with SP1 or later), Windows Server 2003 SP2

Reference

AnnImageObject Members
Leadtools.Annotations Namespace
