AnnNoteObject Class

Visual Basic
C#
Objective-C
Java
C++

[SerializableAttribute()]
public class AnnNoteObject : AnnTextObject, IAnnTextObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Declaration

<SerializableAttribute()>
Public Class AnnNoteObject
   Inherits AnnTextObject
   Implements IAnnTextObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Usage

Dim instance As AnnNoteObject

[SerializableAttribute()]
public ref class AnnNoteObject : public AnnTextObject, IAnnTextObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

The note annotation object is a rectangle with a shadow border and color background (yellow by default). It contains a text string with font properties. The text will wrap on word breaks within the object's specified rectangle. For more information about the note annotation object refer to AnnNoteObject. For more information about the automated note annotation object, refer to Annotation Objects - Automated Features.

Visual Basic
C#
WinRT C#
WinRT JavaScript
Silverlight C#
Silverlight VB

Copy Code

Imports Leadtools
Imports Leadtools.Annotations
Imports Leadtools.Codecs
Imports Leadtools.WinForms

Private Sub AnnNoteObject_AnnNoteObject(ByVal container As AnnContainer, ByVal textString As String)
   Dim note As AnnNoteObject = New AnnNoteObject()
   note.Text = textString
   note.Font = New AnnFont("Arial", New AnnLength(10, AnnUnit.Point), FontStyle.Regular)
   note.EdgeMargin = AnnLength.Empty
   note.ShadowBorderWidth = New AnnLength(6, AnnUnit.Pixel)
   note.Alignment = StringAlignment.Center
   note.LineAlignment = StringAlignment.Center
   note.Bounds = New AnnRectangle(100, 200, 400, 600, AnnUnit.Pixel)
   container.Objects.Add(note)
End Sub

using Leadtools;
   using Leadtools.Annotations;
   using Leadtools.Codecs;
   using Leadtools.WinForms;

   private void AnnNoteObject_AnnNoteObject(AnnContainer container, string textString)
{
   AnnNoteObject note = new AnnNoteObject();
   note.Text = textString;
   note.Font = new AnnFont("Arial", new AnnLength(10, AnnUnit.Point), FontStyle.Regular);
   note.EdgeMargin = AnnLength.Empty;
   note.ShadowBorderWidth = new AnnLength(6, AnnUnit.Pixel);
   note.Alignment = StringAlignment.Center;
   note.LineAlignment = StringAlignment.Center;
   note.Bounds = new AnnRectangle(100, 200, 400, 600, AnnUnit.Pixel);
   container.Objects.Add(note);
}
