AnnTextObject Class

Visual Basic
C#
Objective-C
Java
C++

[SerializableAttribute()]
public class AnnTextObject : AnnRectangleObject, IAnnTextObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Declaration

<SerializableAttribute()>
Public Class AnnTextObject
   Inherits AnnRectangleObject
   Implements IAnnTextObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

'Usage

Dim instance As AnnTextObject

[SerializableAttribute()]
public ref class AnnTextObject : public AnnRectangleObject, IAnnTextObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable

The text annotation object is a text string within a bounding rectangle. This class supports a pen and brush, that may be used on the bounding rectangle, if needed.
For more information, refer to Using Text in Annotation Object. For more information about the text annotation object refer to AnnTextObject. For more information about the automated text annotation object, refer to Annotation Objects - Automated Features.

Visual Basic
C#
WinRT C#
WinRT JavaScript
Silverlight C#
Silverlight VB

Copy Code

Imports Leadtools
Imports Leadtools.Annotations
Imports Leadtools.Codecs
Imports Leadtools.WinForms

Private Sub AnnTextObject_AnnTextObject(ByVal container As AnnContainer, ByVal textString As String)
   Dim text As AnnTextObject = New AnnTextObject()
   text.Pen = New AnnPen(Color.Red, New AnnLength(3))
   text.Text = textString
   text.Brush = Nothing
   text.Font = New AnnFont("Arial", New AnnLength(10, AnnUnit.Point), FontStyle.Regular)
   text.EdgeMargin = AnnLength.Empty
   text.Alignment = StringAlignment.Center
   text.LineAlignment = StringAlignment.Center
   text.TextRotate = AnnTextRotate.Rotate0
   text.Bounds = New AnnRectangle(100, 100, 100, 100, AnnUnit.Pixel)
   container.Objects.Add(text)
End Sub

using Leadtools;
using Leadtools.Annotations;
using Leadtools.Codecs;
using Leadtools.WinForms;

private void AnnTextObject_AnnTextObject(AnnContainer container, string textString)
{
   AnnTextObject text = new AnnTextObject();
   text.Pen = new AnnPen(Color.Red, new AnnLength(3));
   text.Text = textString;
   text.Brush = null;
   text.Font = new AnnFont("Arial", new AnnLength(10, AnnUnit.Point), FontStyle.Regular);
   text.EdgeMargin = AnnLength.Empty;
   text.Alignment = StringAlignment.Center;
   text.LineAlignment = StringAlignment.Center;
   text.TextRotate = AnnTextRotate.Rotate0;
   text.Bounds = new AnnRectangle(100, 100, 100, 100, AnnUnit.Pixel);
   container.Objects.Add(text);
}

Target Platforms

Reference

AnnTextObject Members
Leadtools.Annotations Namespace
