| Leadtools.Annotations Namespace : AnnCurveObject Class |
[SerializableAttribute()] public class AnnCurveObject : AnnPolylineObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
'Declaration <SerializableAttribute()> Public Class AnnCurveObject Inherits AnnPolylineObject Implements System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
'Usage Dim instance As AnnCurveObject
[SerializableAttribute()] public ref class AnnCurveObject : public AnnPolylineObject, System.ICloneable, System.IDisposable, System.Runtime.Serialization.ISerializable
The curve object is a spline curve that contains a collection of AnnPoint points, a Tension value and an AnnPen pen. For more information about the curve annotation object refer to AnnCurveObject. For more information about the automated curve annotation object, refer to Annotation Objects - Automated Features.
This example creates a curve object.
Copy Code
Imports Leadtools Imports Leadtools.Annotations Imports Leadtools.Codecs Imports Leadtools.WinForms Private Sub AnnCurveObject_AnnCurveObject(ByVal container As AnnContainer) Dim curve As AnnCurveObject = New AnnCurveObject() curve.Points.Add(New AnnPoint(100, 100, AnnUnit.Pixel)) curve.Points.Add(New AnnPoint(200, 100, AnnUnit.Pixel)) curve.Points.Add(New AnnPoint(200, 200, AnnUnit.Pixel)) curve.Points.Add(New AnnPoint(100, 300, AnnUnit.Pixel)) curve.Pen = New AnnPen(Color.Red, New AnnLength(1, AnnUnit.Pixel)) curve.Tension = 1 container.Objects.Add(curve) End Sub
using Leadtools; using Leadtools.Annotations; using Leadtools.Codecs; using Leadtools.WinForms; private void AnnCurveObject_AnnCurveObject(AnnContainer container) { AnnCurveObject curve = new AnnCurveObject(); curve.Points.Add(new AnnPoint(100, 100, AnnUnit.Pixel)); curve.Points.Add(new AnnPoint(200, 100, AnnUnit.Pixel)); curve.Points.Add(new AnnPoint(200, 200, AnnUnit.Pixel)); curve.Points.Add(new AnnPoint(100, 300, AnnUnit.Pixel)); curve.Pen = new AnnPen(Color.Red, new AnnLength(1, AnnUnit.Pixel)); curve.Tension = 1; container.Objects.Add(curve); }
