LensFlareCommand Class

C#
Visual Basic
WinRT C#
Objective-C
Java
WinRT JavaScript
C++

public class LensFlareCommand : Leadtools.ImageProcessing.RasterCommand, Leadtools.ImageProcessing.IRasterCommand

'Declaration

Public Class LensFlareCommand
   Inherits Leadtools.ImageProcessing.RasterCommand
   Implements Leadtools.ImageProcessing.IRasterCommand

'Usage

Dim instance As LensFlareCommand

public sealed class LensFlareCommand : Leadtools.ImageProcessing.IRasterCommand

function Leadtools.ImageProcessing.SpecialEffects.LensFlareCommand()

public ref class LensFlareCommand : public Leadtools.ImageProcessing.RasterCommand, Leadtools.ImageProcessing.IRasterCommand

Secondary reflections are caused when bright lights are facing the camera lens. These reflections can show up as spots or banding. The command adds this effect to the image by controlling their number, position, brightness and size of the spots or banding. Each lens type has its own spot distribution and ray thickness.
This command supports 12- and 16-bit grayscale and 48- and 64-bit color images. Support for 12- and 16-bit grayscale and 48- and 64-bit color images is available only in the Document/Medical toolkits.
This command does not support signed data images.
For an example, see the following figure:
The following figure shows the same image, after the effect has been applied:
This command does not support 32-bit grayscale images.

For more information, refer to Correcting Colors.

Run the LensFlareCommand on an image.

C#
Visual Basic
WinRT C#
WinRT JavaScript
Silverlight C#
Silverlight VB

Copy Code

Imports Leadtools
Imports Leadtools.Codecs
Imports Leadtools.ImageProcessing.SpecialEffects

<TestMethod()> _
Public Sub LensFlareCommandExample()
   Dim codecs As New RasterCodecs()
   codecs.ThrowExceptionsOnInvalidImages = True
   Dim leadImage As RasterImage = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "sample5.cmp"))

   ' Prepare the command
   Dim command As LensFlareCommand = New LensFlareCommand
   'Set the center point in the middle of the first square.
   command.CenterPoint = New LeadPoint(leadImage.Width \ 4, leadImage.Height \ 4)
   command.Brightness = 100
   command.Type = LensFlareCommandType.Type1
   command.Color = New RasterColor(100, 150, 10)
   ' Apply the lens flare effect to the image.
   command.Run(leadImage)
   codecs.Save(leadImage, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24)

End Sub

Public NotInheritable Class LEAD_VARS
Public Const ImagesDir As String = "C:\Users\Public\Documents\LEADTOOLS Images"
End Class

using Leadtools;
using Leadtools.Codecs;
using Leadtools.ImageProcessing.SpecialEffects;

[TestMethod]
public void LensFlareCommandExample()
{
   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.ThrowExceptionsOnInvalidImages = true;
   RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "sample5.cmp"));

   // Prepare the command
   LensFlareCommand command = new LensFlareCommand();
   //Set the center point in the middle of the first square.
   command.CenterPoint = new LeadPoint(image.Width / 4, image.Height / 4);
   command.Brightness = 100;
   command.Type = LensFlareCommandType.Type1;
   command.Color = new RasterColor(100, 150, 10);
   // Apply the lens flare effect to the image.
   command.Run(image);
   codecs.Save(image, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24);

}

static class LEAD_VARS
{
public const string ImagesDir = @"C:\Users\Public\Documents\LEADTOOLS Images";
}

using Leadtools;
using Leadtools.Codecs;
using Leadtools.ImageProcessing.SpecialEffects;

[TestMethod]
public async Task LensFlareCommandExample()
{
   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.ThrowExceptionsOnInvalidImages = true;
   string srcFileName = @"Assets\Image1.cmp";
   StorageFile loadFile = await Tools.AppInstallFolder.GetFileAsync(srcFileName);
   RasterImage image = await codecs.LoadAsync(LeadStreamFactory.Create(loadFile));

   // Prepare the command
   LensFlareCommand command = new LensFlareCommand();
   //Set the center point in the middle of the first square.
   command.CenterPoint = LeadPointHelper.Create(image.Width / 4, image.Height / 4);
   command.Brightness = 100;
   command.Type = LensFlareCommandType.Type1;
   command.Color = RasterColorHelper.Create(100, 150, 10);
   // Apply the lens flare effect to the image.
   command.Run(image);

   string destFileName = @"result.bmp";
   StorageFile saveFile = await Tools.AppLocalFolder.CreateFileAsync(destFileName);
   await codecs.SaveAsync(image, LeadStreamFactory.Create(saveFile), RasterImageFormat.Bmp, 24);
}
