DesaturateCommand Class

Summary

Converts the image to a grayscale level by reducing the saturation of each color to zero. The conversion will not change the color resolution.

Syntax

Objective-C

C++/CLI

Java

Python

public class DesaturateCommand : RasterCommand

@interface LTDesaturateCommand : LTRasterCommand

public class DesaturateCommand
    extends RasterCommand

public ref class DesaturateCommand : public RasterCommand

class DesaturateCommand(RasterCommand):

Remarks

The image is converted to a grayscale level by reducing the saturation of each color to zero.
This class supports only RGB images. It does not support grayscale images.
Support for 48-bit and 64-bit colored images are available only in the Document/Medical toolkits.
This class does not support signed data images.
This command does not support 32-bit grayscale images.

For more information, refer to Introduction to Image Processing With LEADTOOLS. For more information, refer to Grayscale Images.

Desaturate Function - Before

Desaturate Function - After

View additional platform support for this Desaturate function.

Example

Run the DesaturateCommand on an image.

Java

using Leadtools;
using Leadtools.Codecs;
using Leadtools.ImageProcessing.Color;


public void DesaturateCommandExample()
{
   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.ThrowExceptionsOnInvalidImages = true;

   RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "sample5.cmp"));

   // Prepare the command
   // Apply deSaturate effect on the image.
   DesaturateCommand command = new DesaturateCommand();
   command.Run(image);
   codecs.Save(image, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24);

}

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\LEADTOOLS23\Resources\Images";
}


import java.io.File;
import java.io.IOException;

import org.junit.*;
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
import static org.junit.Assert.*;

import leadtools.*;
import leadtools.codecs.*;
import leadtools.imageprocessing.color.*;


public void desaturateCommandExample() {

   final String LEAD_VARS_IMAGES_DIR = "C:\\LEADTOOLS23\\Resources\\Images";

   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.setThrowExceptionsOnInvalidImages(true);

   RasterImage image = codecs.load(combine(LEAD_VARS_IMAGES_DIR, "sample5.cmp"));

   // Prepare the command
   // Apply desaturate effect on the image
   DesaturateCommand command = new DesaturateCommand();
   command.run(image);
   codecs.save(image, combine(LEAD_VARS_IMAGES_DIR, "Result.jpg"), RasterImageFormat.JPEG, 24);

   System.out.println("Command run and output image saved to " + combine(LEAD_VARS_IMAGES_DIR, "Result.jpg"));
   assertTrue(new File(combine(LEAD_VARS_IMAGES_DIR, "Result.jpg")).exists());

}
