SampleTargetCommand Class

Summary

Corrects color values by shifting the sample colors to the target colors. This command is available in the Imaging and above toolkits.

Syntax

C++/CLI

Python

public class SampleTargetCommand : RasterCommand

public ref class SampleTargetCommand : public RasterCommand

class SampleTargetCommand(RasterCommand):

Remarks

For example, suppose you are working with a color image. In the SampleColor property or the sampleColor parameter, set the red value portion of the RasterColor structure to 125, the green portion to 165 and the blue portion to 100. In the TargetColor property or the targetColor parameter you set the red value portion to 170, the green to 120 and the blue to 200. If you set SampleTargetCommandFlags.Blue in the Flags property or the flags parameter, then for every pixel in the image that has a blue value of 100, that blue value will be changed to 200, thus shifting the colors in the image. Depending on whether you set SampleTargetCommandFlags.Low, SampleTargetCommandFlags.Mid, or SampleTargetCommandFlags.High, either the shadow values in the blue channel will be remapped, or the midtone values in the blue channel will be remapped, or the highlight values in the blue channel will be remapped.
This command supports 12 and 16-bit grayscale and 48 and 64-bit color images.
For gray scale images the gray value of the SampleColor and TargetColor properties or the sampleColor and targetColor parameters are used, and the different channel flags have the same effect since it works on the same channel (gray channel). Support for 12 and 16-bit grayscale and 48 and 64-bit color images is available only in the Document/Medical toolkits.
This command does not support signed data images.
This command does not support 32-bit grayscale images.

For more information, refer to Introduction to Image Processing With LEADTOOLS. For more information, refer to Correcting Colors.

Sample Target Function - Before

Sample Target Function - After

View additional platform support for this Sample Target function.

Example

Run the SampleTargetCommand on an image.

using Leadtools;
using Leadtools.Codecs;
using Leadtools.ImageProcessing.Color;


public void SampleTargetCommandExample()
{
   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.ThrowExceptionsOnInvalidImages = true;

   RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "sample5.cmp"));

   // Prepare the command
   SampleTargetCommand command = new SampleTargetCommand();
   command.SampleColor = new RasterColor(50, 100, 150);
   command.TargetColor = new RasterColor(60, 90, 150);
   command.Flags = SampleTargetCommandFlags.Red | SampleTargetCommandFlags.High;
   command.Run(image);
   codecs.Save(image, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24);

}

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\LEADTOOLS23\Resources\Images";
}
