←Select platform

In This Topic ▼

EmbossCommand Class

Summary

Applies an emboss effect to an image, letting you specify the depth and direction of the effect.

Syntax

C#

Objective-C

C++/CLI

Java

Python

public class EmbossCommand : RasterCommand

@interface LTEmbossCommand : LTRasterCommand

public class EmbossCommand
    extends RasterCommand

public ref class EmbossCommand : public RasterCommand

class EmbossCommand(RasterCommand):

Remarks

This command supports 12 and 16-bit grayscale and 48 and 64-bit color images. Support for 12 and 16-bit grayscale and 48 and 64-bit color images is available only in the Document/Medical toolkits.
This command does not support 32-bit grayscale images.

For more information, refer to Applying Artistic Effects.

Emboss Function - Before

Emboss Function - Before

Emboss Function - After

Emboss Function - After

View additional platform support for this Emboss function.

Example

Run the EmbossCommand on an image and embosses it.

C#

Java

using Leadtools;
using Leadtools.Codecs;
using Leadtools.ImageProcessing.Effects;


public void EmbossCommandExample()
{
   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.ThrowExceptionsOnInvalidImages = true;

   RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "ImageProcessingDemo\\NaturalFruits.jpg"));

   // Prepare the command
   EmbossCommand command = new EmbossCommand();
   //Emboss with northeast direction and average depth.
   command.Direction = EmbossCommandDirection.North;
   command.Depth = 500;
   command.Run(image);
   codecs.Save(image, Path.Combine(LEAD_VARS.ImagesDir, "Result.jpg"), RasterImageFormat.Jpeg, 24);

}

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\LEADTOOLS23\Resources\Images";
}


import java.io.File;
import java.io.IOException;

import org.junit.*;
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
import static org.junit.Assert.assertTrue;

import leadtools.*;
import leadtools.codecs.*;
import leadtools.imageprocessing.effects.*;


public void embossCommandExample() {

   final String LEAD_VARS_IMAGES_DIR = "C:\\LEADTOOLS23\\Resources\\Images";

   // Load an image
   RasterCodecs codecs = new RasterCodecs();
   codecs.setThrowExceptionsOnInvalidImages(true);
   RasterImage image = codecs.load(combine(LEAD_VARS_IMAGES_DIR, "NaturalFruits.jpg"));

   // Prepare the command
   EmbossCommand command = new EmbossCommand();

   // Emboss with northeast direction and average depth.
   command.setDirection(EmbossCommandDirection.NORTH);
   command.setDepth(500);
   int change = command.run(image);
   assertTrue(change != RasterImageChangedFlags.NONE);

   codecs.save(image, combine(LEAD_VARS_IMAGES_DIR, "Result.jpg"), RasterImageFormat.JPEG, 24);
   System.out.println("Command run and image saved to " + combine(LEAD_VARS_IMAGES_DIR, "Result.jpg"));
}

Requirements

Target Platforms

See Also

Reference

EmbossCommand Members

Leadtools.ImageProcessing.Effects Namespace

Applying Artistic Effects
