StitchCommand Class

Summary

Provides a method to stitch together a list of RasterImages with a given set of stitching options.

Syntax
C#
C++/CLI
Python
public class StitchCommand : RasterCommand
public:
   ref class StitchCommand : RasterCommand
class StitchCommand(RasterCommand):
Remarks

StitchCommand does not support merging images with different scales, orientations, and rotations. However, stitching results on images that are at the same scale, orientation, and rotation, can be optimized with StitchImageType, StitchMethodType, and/or StitchSideMatchingType.

Stitch Function - Before

Stitch Function - Before

Stitch Function - After

Stitch Function - After

View additional platform support for this Stitch function.

Example
C#
using Leadtools;
using Leadtools.Codecs;
using Leadtools.ImageProcessing.Effects;


public void StitchCommandExample()
{

   IList<RasterImage> Images = new List<RasterImage>();
   RasterCodecs codecs = new RasterCodecs();

   // Load images
   for (int i = 1; i <= 4; i++)
   {

      codecs.ThrowExceptionsOnInvalidImages = true;
      RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, $"cannon{i}.jpg"));
      Images.Add(image);
   }

   // The first image to stitch together
   var firstImage = Images.First();

   try
   {
      var toStitchImages = Images.Skip(1).ToList();
      try
      {
         // Create new Stitch Command and run on the provided images with the given parameters
         // If successful, the firstImage will be updated to a stitched image
         new StitchCommand
         {
            ImageType = StitchImageType.Picture,
            ToStitchImages = toStitchImages,
            MethodType = StitchMethodType.Exhaustive,
            SideMatchingType = StitchSideMatchingType.KeepLeft,
            MinimumOverlap = 0.0
         }.Run(firstImage);

         codecs.Save(firstImage, Path.Combine(LEAD_VARS.ImagesDir, "cannonStitched.jpg"), RasterImageFormat.Jpeg411, 24);
         firstImage.Dispose();
         codecs.Dispose();
         Images.Clear();
      }
      catch (Exception e)
      {
         Assert.Fail(e.Message);
         Console.WriteLine(e);
      }
   }
   catch (Exception e)
   {
      Console.WriteLine(e);
      Assert.Fail(e.Message);
   }
}

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\LEADTOOLS23\Resources\Images";
}
Requirements

Target Platforms
