GetParentElement Method

Summary

Returns the item in the Data Set that is the parent of the specified item.

Syntax

C#
VB
Java
WinRT C#
C++
public DicomElement GetParentElement(
   DicomElement element
)
Public Function GetParentElement( _
   ByVal element As Leadtools.Dicom.DicomElement _
) As Leadtools.Dicom.DicomElement
public DicomElement getParentElement(DicomElement element)
 function Leadtools.Dicom.DicomDataSet.GetParentElement(
   element
)

Parameters

element
An item in the Data Set.

Return Value

The item in the Data Set that is the parent of the item specified by element, or a null reference (Nothing in VB) if element has no parent (element is a Level 0 item).

Remarks

The parent is the ancestor one level higher than the specified item. If the specified item is a Level 0 item, this method will return a null reference (Nothing in VB). Please note that the numbering of the items in the following illustration is arbitrary and does not imply order.

If the passed object points to: The method returns an object pointing to:
Item 1 null
Item 2 Item 3
Item 4 Item 3
Item 5 Item 6

The following methods will also help you navigate the Data Set:

GetFirstElement

GetLastElement

GetNextElement

GetRootElement

GetChildElement

Example

For an example, refer to Load.
