LDicomDS::GetParentElement

#include "Ltdic.h"

pDICOMELEMENT LDicomDS::GetParentElement(pElement)

Returns a pointer to the item in the Data Set that contains the parent of the specified item.

Parameters

pDICOMELEMENT pElement

Pointer to a DICOMELEMENT structure that contains an item in the Data Set.

Returns

Value Meaning
!NULL A pointer to a DICOMELEMENT structure that contains the item in the Data Set that is the parent of the item specified in pElement.
NULL pElement has no parent. (pElement is a Level 0 item.)

Comments

The parent is the ancestor one level higher than the specified item. If the specified item is a Level 0 item, this function will return NULL.

NOTE: The numbering of the items in this illustration is arbitrary and does not imply order.

|If the passed pointer points to|The function returns a pointer to| |Item 1|NULL| |Item 2|Item 3| |Item 4|Item 3| |Item 5|Item 6|

The following functions will also help you navigate the Data Set:

LDicomDS::GetFirstElement

LDicomDS::GetLastElement

LDicomDS::GetNextElement

LDicomDS::GetRootElement

LDicomDS::GetChildElement

Required DLLs and Libraries

Platforms

Win32, x64

See Also

Functions

Topics

Example

This example displays the parent’s name of an element.

L_INT LDicomDS_GetParentElementExample()
{
   LDicomDS*      pDS;
   pDICOMELEMENT  pParent;
   pDICOMELEMENT  pElement;
   pDICOMTAG      pTag;
   L_TCHAR        szUnknown[]=TEXT("Unknown");
   L_TCHAR*       p;

   pDS = new LDicomDS(NULL);

   pDS->InitDS( CLASS_XA_BIPLANE_IMAGE_STORAGE_RETIRED, 0);

   pElement = pDS->FindFirstElement(NULL, TAG_RADIATION_SETTING, FALSE);
   if (pElement != NULL)
   {
      pParent = pDS->GetParentElement(pElement);
      if (pParent != NULL)
      {
         pTag = LDicomTag::Find(pParent->nTag);
         if (pTag != NULL)
         {
            p = pTag->pszName;
         }
         else
         {
            p = szUnknown;
         }

         MessageBox(NULL, p, TEXT("Notice"), MB_OK);
      }
   }

   delete pDS;

   return DICOM_SUCCESS;
}
