ShrinkWrapCommand Class

Summary
Performs automated segmentation of a rectangular or circular area in the specified image using the specified threshold.
Syntax
C#
Objective-C
C++/CLI
Java
Python
public class ShrinkWrapCommand : RasterCommand
@interface LTShrinkWrapCommand : LTRasterCommand
public class ShrinkWrapCommand
    extends RasterCommand
public ref class ShrinkWrapCommand : public RasterCommand
class ShrinkWrapCommand(RasterCommand):
Remarks

The result is applied to the image as a region. This function was designed specifically for CT/MRI images, to segment regions of cancer clusters.

  • Use MakeRegionEmpty to delete the resulting region.
  • The radius must not exceed the length of the image diagonal or the class will throw an Invalid Parameters exception and will not execute.
  • This command does not support 32-bit grayscale images.
  • This command supports signed/unsigned images.

Shrink Wrap Tool Function - Before

Shrink Wrap Tool Function - Before

Shrink Wrap Tool Function - After

Shrink Wrap Tool Function - After

View additional platform support for this Shrink Wrap Tool function.

Example
C#
Java
using Leadtools;
using Leadtools.Codecs;
using Leadtools.ImageProcessing.Core;


public void ShrinkWrapCommandExample()
{
   RasterCodecs codecs = new RasterCodecs();
   codecs.ThrowExceptionsOnInvalidImages = true;

   //Load an image
   RasterImage image = codecs.Load(Path.Combine(LEAD_VARS.ImagesDir, "IMAGE3.dcm"));

   //Prepare the command
   ShrinkWrapCommand command = new ShrinkWrapCommand();

   command.Threshold = 60;
   command.Radius = 100;
   command.Center = new LeadPoint(245, 230);
   command.Flags = ShrinkWrapFlags.ShrinkRect | ShrinkWrapFlags.RgnSet;

   //Apply
   command.Run(image);
}

static class LEAD_VARS
{
   public const string ImagesDir = @"C:\LEADTOOLS23\Resources\Images";
}

import java.io.File;
import java.io.IOException;

import org.junit.*;
import org.junit.runner.JUnitCore;
import org.junit.runner.Result;
import org.junit.runner.notification.Failure;
import static org.junit.Assert.assertTrue;

import leadtools.*;
import leadtools.codecs.*;
import leadtools.imageprocessing.core.*;


public void shrinkWrapCommandExample() {

   final String LEAD_VARS_IMAGES_DIR = "C:\\LEADTOOLS23\\Resources\\Images";

   RasterCodecs codecs = new RasterCodecs();
   codecs.setThrowExceptionsOnInvalidImages(true);

   // Load an image
   RasterImage image = codecs.load(combine(LEAD_VARS_IMAGES_DIR, "DICOM\\IMAGE3.dcm"));

   // Prepare the command
   ShrinkWrapCommand command = new ShrinkWrapCommand();

   command.setThreshold(60);
   command.setRadius(100);
   command.setCenter(new LeadPoint(245, 230));
   command.setFlags(ShrinkWrapFlags.SHRINK_RECT.getValue() | ShrinkWrapFlags.RGN_SET.getValue());

   // Apply
   int change = command.run(image);
   assertTrue(change != RasterImageChangedFlags.NONE);

   // Save the image
   String outputFileName = combine(LEAD_VARS_IMAGES_DIR, "DICOM\\IMAGE3.dcm");
   codecs.save(image, outputFileName, RasterImageFormat.DICOM_JPEG_LS_COLOR, 0);
   System.out.println("Command run, file saved to " + outputFileName);
}
