Datamatrix is a two-dimensional matrix barcode consisting of black and white square modules arranged in either a square or rectangular pattern. The encoded information can be text or binary. Typical data storage size is from a few bytes up to 2 kilobytes. The total storage of the encoded data depends on the symbol's dimensions.
Symbology | ||
---|---|---|
BarcodeSymbology.Datamatrix | Datamatrix barcodes also include error correction codes which increase symbol robustness. This means that a partially damaged Datamatrix barcode can still be successfully and accurately decoded. |
Data Options | Member |
---|---|
LEADTOOLS Symbology Identifier | BarcodeSymbology.Datamatrix |
Data Class | DatamatrixBarcodeData |
Read Options | DatamatrixBarcodeReadOptions |
Write Options | DatamatrixBarcodeWriteOptions |
Uses Error Correction Code (ECC) to reconstruct damaged barcode symbols
Stores up to 2,218 ASCII characters in one barcode symbol
Chains multiple symbols together to encode up to 33,225 characters
Datamatrix type DatamatrixBarcodeSymbolSize |
Maximum Numeric Length |
Maximum Alphanumeric Length |
Maximum Binary Length |
Maximum Correctable Error / Erasure |
---|---|---|---|---|
10 x 10 | 6 | 3 | 1 | 2 |
12 x 12 | 10 | 6 | 3 | 3 |
14 x 14 | 16 | 10 | 6 | 5/7 |
16 x 16 | 24 | 16 | 10 | 6/9 |
18 x 18 | 36 | 25 | 16 | 7/11 |
20 x 20 | 44 | 31 | 20 | 9/15 |
22 x 22 | 60 | 43 | 28 | 10/17 |
24 x 24 | 72 | 52 | 34 | 12/21 |
26 x 26 | 88 | 64 | 42 | 14/25 |
32 x 32 | 124 | 91 | 60 | 18/33 |
36 x 36 | 172 | 127 | 84 | 21/39 |
40 x 40 | 228 | 169 | 112 | 24/45 |
44 x 44 | 288 | 214 | 142 | 28/53 |
48 x 48 | 348 | 259 | 172 | 34/65 |
52 x 52 | 408 | 304 | 202 | 42/78 |
64 x 64 | 560 | 418 | 278 | 56/106 |
72 x 72 | 736 | 550 | 366 | 72/132 |
80 x 80 | 912 | 682 | 454 | 96/180 |
88 x 88 | 1152 | 862 | 574 | 112/212 |
96 x 96 | 1392 | 1042 | 694 | 136/260 |
104 x 104 | 1632 | 1222 | 814 | 168/318 |
120 x 120 | 2100 | 1573 | 1048 | 204/390 |
132 x 132 | 2608 | 1954 | 1302 | 248/472 |
144 x 144 | 3116 | 2335 | 1556 | 310/590 |
8 x 18 | 10 | 6 | 3 | 3 |
8 x 32 | 20 | 13 | 8 | 5 |
12 x 26 | 32 | 22 | 14 | 7/11 |
12 x 36 | 44 | 31 | 20 | 9/15 |
16 x 36 | 64 | 46 | 30 | 12/21 |
16 x 48 | 98 | 72 | 47 | 14/25 |
