LBitmap::GlowFilter
Summary
Makes the colored edges shine with a neon glow.
Syntax
#include "ltwrappr.h"
virtual L_INT LBitmap::GlowFilter (uDim, uBright, uThreshold, uFlags = 0)
Parameters
L_UINT uDim
Size of the neighborhood used to determine the width of the glow.
L_UINT uBright
Brightness factor used to create the "glow". This can be any number that is 0 or greater. If it is 0 the image will be black.
L_UINT uThreshold
Threshold value used to determine which pixels are edge pixels. If the difference determined for a pixel is greater than this value, the pixel is an edge pixel. Valid values ranges are:
- 0 to 65535 for 64-bit, 48-bit and 16-bit grayscale images.
- 0 to 4095 for 12-bit grayscale images.
- 0 to 255 otherwise.
Use this parameter to control the number of edge pixels found.
L_UINT32 uFlags
Reserved for future use. Must be 0.
Returns
| Value | Meaning |
|---|---|
| SUCCESS | The function was successful. |
| < 1 | An error occurred. Refer to Return Codes. |
Comments
This function detects the edge pixels by comparing the values of the pixel with surrounding pixels and if the edge value (the difference between the surrounding pixels and the pixel being evaluated) is greater than the Threshold value, the pixel is an edge pixel. The function then multiplies the values for the edge pixels by the uBright Brightness factor.
This function supports 12 and 16-bit grayscale and 48 and 64-bit color images. Support for 12 and 16-bit grayscale and 48 and 64-bit color images is available only in the Document/Medical toolkits.
To update a status bar or detect a user interrupt during execution of this function, refer to LBase::EnableStatusCallback.
To obtain this effect, the following settings were used with the function:
uDim = 15;
uBright = 5;
uThreshold = 0;
This function does not support signed data images. It returns the error code ERROR_SIGNED_DATA_NOT_SUPPORTED if a signed data image is passed to this function.
This function does not support 32-bit grayscale images. It returns the error code ERROR_GRAY32_UNSUPPORTED if a 32-bit grayscale image is passed to this function.
Glow Function - Before
Glow Function - After
View additional platform support for this Glow function.
Required DLLs and Libraries
- LTIMGSFX
- For a listing of the exact DLLs and Libraries needed, based on the toolkit version, refer to Files To Be Included With Your Application.
Platforms
Win32, x64.
See Also
Functions
- LBitmap::DiffuseGlow
- LBitmap::HighPassFilter
- LBitmap::MaskConvolution
- LBitmap::AdjustTint
- LBitmap::ColorHalfTone
- LBitmap::AddNoise
- LBitmap::Emboss
- LBitmap::Mosaic
- LBitmap::MotionBlur
- LBitmap::Oilify
- LBitmap::Posterize
- LBitmap::RemoveRedeye
- LBitmap::Solarize
- LBitmapBase::Underlay
- LBitmap::BumpMap
- LBitmap::Cubism
- LBitmap::DrawStar
- LBitmap::Dry
- LBitmap::FreePlaneBend
- LBitmap::FreeRadBend
- LBitmap::GlassEffect
- LBitmap::LensFlare
- LBitmap::Light
- LBitmap::Ocean
- LBitmap::PlaneBend
- LBitmap::Plane
- LBitmap::SampleTarget
- LBitmap::Tunnel
- LBitmap::Bending
- LBitmap::Cylindrical
- LBitmap::FreeHandShear
- LBitmap::FreeHandWave
- LBitmap::Impressionist
- LBitmap::Pixelate
- LBitmap::Polar
- LBitmap::Punch
- LBitmap::RadialBlur
- LBitmap::RadWave
- LBitmap::Ripple
- LBitmap::Spherize
- LBitmap::Swirl
- LBitmap::Wave
- LBitmap::Wind
- LBitmap::ZoomBlur
- LBitmap::ZoomWave
Topics
- Raster Image Functions: Filtering Images
- Raster Image Functions: Artistic Effects
- Applying Artistic Effects
- Raster Image Functions: Correcting Colors
- Raster Image Functions: Detecting and Enhancing Edges and Lines
Example
L_INT LBitmap__GlowFilterExample(LAnimationWindow *BitmapWindow){return BitmapWindow->GlowFilter(5, 3, 0);}
