LBitmap::Impressionist

Summary

Makes a bitmap look like it was painted by an impressionist painter.

Syntax

#include "ltwrappr.h"

virtual L_INT LBitmap::Impressionist(uHorzDim, uVertDim, uFlags = 0)

Parameters

L_UINT uHorzDim

Horizontal effect size, in pixels. Possible values range from 1 to 100.

L_UINT uVertDim

Vertical effect size, in pixels. Possible values range from 1 to 100.

L_UINT32 uFlags

Reserved for future use. Must be 0.

Returns

Value	Meaning
SUCCESS	The function was successful.
< 1	An error occurred. Refer to Return Codes.

Comments

This function supports 12 and 16-bit grayscale and 48 and 64-bit color images. Support for 12 and 16-bit grayscale and 48 and 64-bit color images is available only in the Document/Medical toolkits.

This function does not support signed data images. It returns the error code ERROR_SIGNED_DATA_NOT_SUPPORTED if a signed data image is passed to this function.

This function does not support 32-bit grayscale images. It returns the error code ERROR_GRAY32_UNSUPPORTED if a 32-bit grayscale image is passed to this function.

Impressionist Function - Before

Impressionist Function - After

View additional platform support for this Impressionist function.

Required DLLs and Libraries

LTIMGSFX
For a listing of the exact DLLs and Libraries needed, based on the toolkit version, refer to Files To Be Included With Your Application.

Platforms

Win32, x64.

Example

L_INT LBitmap__ImpressionistExample(LAnimationWindow * pAniWnd)
{

  return pAniWnd->Impressionist( 10, 10);

}
