LBitmap::Segment

Summary

Divides the bitmap into segments where each segments pixels have approximately the same color (homogenous color).

Syntax

#include "ltwrappr.h"

virtual L_INT LBitmap::Segment(uThreshold, uFlags)

Parameters

L_UINT uThreshold

The tolerance value of each segment. Valid values for this parameter are:

0 to 255 for 1, 2, 3, 4, 5, 6, 7, 8, 24, and 32-bit bitmaps.
0 to 4095 for 12-bit bitmaps.
0 to 65535 for 16, 48, and 64-bit bitmaps.

L_UINT uFlags

Flag that indicates the color space used in the segmentation. Possible values are:

Value	Meaning
SGM_RGB	[0x00001] Comparison done on red, green and blue difference.
SGM_Y	[0x00002] Comparison done on Y channel difference of YUV space.
SGM_U	[0x00003] Comparison done on U channel difference of YUV space.
SGM_V	[0x00004] Comparison done on V channel difference of YUV space.
SGM_UV	[0x00005] Comparison done on U and V channels difference of YUV space.
SGM_NGTV_UV	[0x00010] Consider negative values of U and V of YUV color space. This flag is used only with the SGM_U or SGM_V flags.

Returns

Value	Meaning
SUCCESS	The function was successful.
< 1	An error occurred. Refer to Return Codes.

Comments

This function divides the images into segments according to its pixel values . The segment shapes will be arbitrary. Adjacent pixels with approximately the same values are put together into homogenous segments. The function may be performed on the RGB and YUV color spaces.

To update a status bar or detect a user interrupt during execution of this function, refer to LBase::EnableStatusCallback.

This function supports 12 and 16-bit grayscale and 48 and 64-bit color images. Support for 12 and 16-bit grayscale and 48 and 64-bit color images is available only in the Document/Medical toolkits.

This function does not support signed data images. It returns the error code ERROR_SIGNED_DATA_NOT_SUPPORTED if a signed data image is passed to this function.

This function does not support 32-bit grayscale images. It returns the error code ERROR_GRAY32_UNSUPPORTED if a 32-bit grayscale image is passed to this function.

Segment Function - Before

Segment Function - After

View additional platform support for this Segment function.

Required DLLs and Libraries

LTIMGCLR
For a listing of the exact DLLs and Libraries needed, based on the toolkit version, refer to Files To Be Included With Your Application.

Platforms

Win32, x64.

Example

L_INT LBitmap__SegmentExample(LBitmap *pLeadBitmap)
{

   /* segment the bitmap */
   return pLeadBitmap->Segment (20,  SGM_RGB);

}
